Fujitsu WOYA080LFCA Design & Technical Manual

- (HU01 - 05) -
Hydraulic unit / Split DHW integrated
HYDRAULIC UNIT WG

050-160DG

HYDRAULIC UNIT WG

050-160DG

ELECTRICAL SPECIFICATIONS2-2.
COMFORT SERIES

Model name (Hydraulic unit)
WGYA050DG6
WGHA050DG
WGYA100DG6
WGHA100DG
Model name (Outdoor unit)
WOYA060LFCA
WOHA060LFCA
WOYA060LFCA
WOHA060LFCA
WOYA080LFCA
WOHA080LFCA
WOYA100LFTA
WOHA100LFTA
Electrical heater*
(backup-heater)
Type Copper 9W / cm
2
Power supply
Phase 1
Frequency Hz 50
Voltage V 230
Current
Running current
A
26.1
Max. operating
current
(Hydraulic unit)
28.2 A + 10%
Electrical heater
(DHW heater)
Type Copper 8.5W / cm
2
Power supply
Phase 1
Frequency Hz 50
Voltage V 230
Current
Running current
A
6.5
Max. operating
current
(Hydraulic unit)
7.0 A + 10%
Wiring specication*
(For back-up heater power supply)
Main fuse (circuit
breaker) current
A 32
Connection cable mm² 6.0 x 3
Wiring specication
(For DHW heater power supply)
Main fuse (circuit
breaker) current
A 16
Connection cable mm² 1.5 x 3
Wiring specication
(Hydraulic unit to Outdoor unit)
Connection cable mm² 1.5 x 4
Limited wiring
length
m Not available
*: WGY model only.
