Fujitsu WOYA080LFCA Design & Technical Manual

- (OU01 - 19) -
Outdoor unit / Single phase
OUTDOOR UNIT WO

A060-100LF
OUTDOOR UNIT WO

A060-100LF
MODEL

: WO

A060LFCA (6.0kW type)
FT : Flow temperature
OT : Outdoor temperature
HC : Heating capacity (kW)
IP : Input power (kW)
COP : Coefcient of performance
The values of heating capacity/power input/COP are based on measurement of EN14511 standard;
FT < 45°C : The ow rate obtained during the test at the standard rating conditions of OT 7°C and Water temp. ow/return 35°C / 30°C, 1040 l/h
FT
>
=
45°C : The ow rate obtained during the test at the standard rating conditions of OT 7°C and Water temp. ow/return 45°C / 40°C, 887 l/h
FT = 55°C : The ow rate obtained during the test at the standard rating conditions of OT 7°C and Water temp. ow/return 55°C / 47°C, 491 l/h
Usage environment, such as operation of the heating equipment, room temperature, and controller adjustments, may cause disparities between practically determined and measured
values.
FT 30°C 35°C 40°C 45°C 50°C 55°C
OT HC IP COP HC IP COP HC IP COP HC IP COP HC IP COP HC IP COP
-20°C 3.72 1.68 2.21 3.67 1.78 2.06 3.60 1.92 1.87 ― ― ― ― ― ― ― ― ―
-19°C 3.79 1.66 2.28 3.74 1.76 2.13 3.67 1.90 1.93 ― ― ― ― ― ― ― ― ―
-18°C 3.87 1.64 2.36 3.82 1.73 2.21 3.75 1.88 1.99 3.77 2.01 1.88 ― ― ― ― ― ―
-17°C 3.95 1.62 2.44 3.89 1.71 2.27 3.82 1.85 2.06 3.82 1.99 1.91 ― ― ― ― ― ―
-16°C 4.02 1.60 2.51 3.97 1.69 2.35 3.90 1.83 2.13 3.86 1.98 1.95 ― ― ― ― ― ―
-15°C 4.10 1.58 2.60 4.04 1.67 2.42 3.97 1.80 2.20 3.91 1.96 1.99 ―
― ― ― ― ―
-14°C 4.17 1.59 2.62 4.11 1.68 2.45 4.04 1.81 2.23 3.98 1.97 2.02 3.68 2.09 1.76 ― ― ―
-13°C 4.25 1.60 2.66 4.18 1.69 2.47 4.11 1.82 2.26 4.05 1.98 2.05 3.75 2.10 1.78 ― ― ―
-12°C 4.32 1.60 2.70 4.25 1.69 2.51 4.18 1.83 2.28 4.11 1.99 2.07 3.82 2.11 1.81 ― ― ―
-11°C 4.39 1.61 2.73 4.32 1.70 2.54 4.25 1.84 2.31 4.18 2.00 2.09 3.88 2.12 1.83 ― ― ―
-10°C 4.46 1.62 2.75 4.39 1.71 2.57 4.32 1.85 2.34 4.25 2.01 2.11 3.95 2.13 1.85 3.53 2.26 1.56
-9°C 4.54 1.63 2.79 4.46 1.72 2.59 4.39 1.85 2.37 4.32 2.02 2.14 4.02 2.14 1.88 3.64 2.28 1.60
-8°C 4.61 1.64 2.81 4.53 1.73 2.62 4.46 1.86 2.40 4.38 2.03 2.16 4.08 2.15
1.90 3.74 2.31 1.62
-7°C 4.68 1.65 2.84 4.60 1.74 2.64 4.53 1.87 2.42 4.45 2.04 2.18 4.15 2.16 1.92 3.85 2.33 1.65
-6°C 4.74 1.63 2.91 4.64 1.72 2.70 4.55 1.84 2.47 4.46 2.00 2.23 4.19 2.13 1.97 3.92 2.32 1.69
-5°C 4.79 1.62 2.96 4.68 1.69 2.77 4.57 1.81 2.52 4.46 1.96 2.28 4.23 2.11 2.00 3.99 2.31 1.73
-4°C 4.85 1.60 3.03 4.72 1.67 2.83 4.60 1.78 2.58 4.47 1.92 2.33 4.27 2.08 2.05 4.07 2.31 1.76
-3°C 4.90 1.59 3.08 4.76 1.65 2.88 4.62 1.75 2.64 4.47 1.88 2.38 4.31 2.06 2.09 4.14 2.30 1.80
-2°C 4.96 1.57 3.16 4.79 1.62 2.96 4.64 1.72 2.70 4.48 1.85 2.42 4.34 2.03 2.14 4.21 2.29 1.84
-1°C 5.01 1.56 3.21 4.83 1.60 3.02 4.66 1.69 2.76 4.48 1.81 2.48 4.38 2.01 2.18
4.28 2.28 1.88
0°C 5.07 1.54 3.29 4.87 1.58 3.08 4.68 1.66 2.82 4.49 1.77 2.54 4.42 1.98 2.23 4.36 2.28 1.91
1°C 5.12 1.53 3.35 4.91 1.55 3.17 4.70 1.63 2.88 4.49 1.73 2.60 4.46 1.96 2.28 4.43 2.27 1.95
2°C 5.18 1.51 3.43 4.95 1.53 3.24 4.73 1.60 2.95 4.50 1.69 2.70 4.50 1.93 2.33 4.50 2.26 1.99
3°C 5.50 1.49 3.69 5.21 1.51 3.45 4.93 1.57 3.14 4.65 1.65 2.82 4.58 1.86 2.46 4.50 2.15 2.09
4°C 5.82 1.47 3.96 5.48 1.49 3.68 5.14 1.55 3.32 4.80 1.62 2.96 4.65 1.80 2.58 4.50 2.05 2.20
5°C 6.45 1.47 4.40 6.00 1.49 4.04 5.55 1.53 3.63 5.10 1.57 3.24 4.80 1.70 2.83 4.50 1.88 2.40
6°C 6.45 1.42 4.54 6.00 1.44 4.16 5.55 1.49 3.73 5.10 1.54 3.32 4.80 1.66 2.89 4.50
1.83 2.46
7°C 6.45 1.38 4.67 6.00 1.41 4.27 5.55 1.45 3.83 5.10 1.50 3.40 4.80 1.62 2.96 4.50 1.79 2.51
8°C 6.45 1.34 4.80 6.00 1.37 4.38 5.55 1.41 3.93 5.10 1.47 3.48 4.80 1.58 3.03 4.50 1.76 2.56
9°C 6.45 1.31 4.94 6.00 1.33 4.50 5.55 1.38 4.03 5.10 1.43 3.56 4.80 1.55 3.09 4.50 1.72 2.62
10°C 6.45 1.27 5.07 6.00 1.30 4.61 5.55 1.34 4.13 5.10 1.40 3.65 4.80 1.52 3.16 4.50 1.69 2.67
11°C 6.45 1.24 5.21 6.00 1.27 4.73 5.55 1.32 4.22 5.10 1.37 3.73 4.80 1.49 3.23 4.50 1.65 2.72
12°C 6.45 1.21 5.34 6.00 1.24 4.84 5.55 1.28 4.32 5.10 1.34 3.81 4.80 1.46 3.29 4.50 1.62 2.78
13°C 6.45 1.18 5.48 6.00 1.21 4.96 5.55 1.26 4.42 5.10 1.31 3.89 4.80 1.43 3.36 4.50 1.59
2.83
14°C 6.45 1.15 5.61 6.00 1.18 5.07 5.55 1.23 4.52 5.10 1.28 3.98 4.80 1.40 3.43 4.50 1.56 2.88
15°C 6.45 1.12 5.75 6.00 1.16 5.19 5.55 1.20 4.62 5.10 1.26 4.06 4.80 1.37 3.50 4.50 1.54 2.93
16°C 6.45 1.10 5.88 6.00 1.13 5.30 5.55 1.18 4.72 5.10 1.23 4.14 4.80 1.35 3.56 4.50 1.51 2.99
17°C 6.45 1.07 6.02 6.00 1.11 5.42 5.55 1.15 4.81 5.10 1.21 4.22 4.80 1.32 3.63 4.50 1.48 3.04
18°C 6.45 1.05 6.15 6.00 1.08 5.53 5.55 1.13 4.91 5.10 1.18 4.31 4.80 1.30 3.70 4.50 1.46 3.09
19°C 6.45 1.03 6.29 6.00 1.06 5.65 5.55 1.11 5.01 5.10 1.16 4.39 4.80 1.28 3.76 4.50 1.43 3.15
20°C 6.45 1.00 6.42 6.00 1.04 5.76 5.55 1.09 5.11 5.10 1.14 4.47 4.80 1.25 3.83 4.50 1.41 3.20
21°C 6.45 1.00 6.48 6.00 1.03 5.82 5.55 1.08 5.16 5.10 1.13 4.51 4.80 1.24 3.86 4.50 1.39 3.23
22°C 6.45 0.98 6.55 6.00 1.02 5.87 5.55 1.07 5.20 5.10 1.12 4.55 4.80 1.23 3.90 4.50 1.38 3.25
23°C 6.45 0.98 6.61 6.00 1.01 5.93 5.55 1.06 5.25 5.10 1.11 4.59 4.80 1.22 3.93 4.50 1.37 3.28
24°C 6.45 0.97 6.67 6.00 1.00 5.98 5.55 1.05 5.30 5.10 1.10 4.63 4.80 1.21 3.96 4.50 1.36 3.31
25°C 6.45 0.96 6.73 6.00 0.99 6.04 5.55 1.04 5.35 5.10 1.09 4.67 4.80 1.20 4.00 4.50 1.35 3.33
26°C 6.45 0.95 6.80 6.00 0.98 6.10 5.55 1.03 5.39 5.10 1.08 4.71 4.80 1.19 4.03 4.50 1.34 3.36
27°C 6.45 0.94 6.86 6.00 0.98 6.15 5.55 1.02 5.44 5.10 1.07 4.75 4.80 1.18 4.06 4.50 1.33 3.39
28°C
6.45 0.93 6.92 6.00 0.97 6.21 5.55 1.01 5.49 5.10 1.06 4.79 4.80 1.17 4.10 4.50 1.32 3.41
29°C 6.45 0.92 6.98 6.00 0.96 6.26 5.55 1.00 5.54 5.10 1.06 4.83 4.80 1.16 4.13 4.50 1.31 3.44
30°C 6.45 0.91 7.05 6.00 0.95 6.32 5.55 0.99 5.58 5.10 1.05 4.87 4.80 1.15 4.16 4.50 1.30 3.47
31°C 6.45 0.91 7.11 6.00 0.94 6.38 5.55 0.99 5.63 5.10 1.04 4.91 4.80 1.14 4.20 4.50 1.29 3.49
32°C 6.45 0.90 7.17 6.00 0.93 6.43 5.55 0.98 5.68 5.10 1.03 4.95 4.80 1.13 4.23 4.50 1.28 3.52
33°C 6.45 0.89 7.23 6.00 0.92 6.49 5.55 0.97 5.73 5.10 1.02 4.99 4.80 1.13 4.26 4.50 1.27 3.55
34°C 6.45 0.88 7.30 6.00 0.92 6.54 5.55 0.96 5.77 5.10 1.01 5.03 4.80 1.12 4.30 4.50 1.26 3.57
35°C 6.45
0.88 7.36 6.00 0.91 6.60 5.55 0.95 5.82 5.10 1.01 5.07 4.80 1.11 4.33 4.50 1.25 3.60
