Fujitsu WOYA080LFCA Design & Technical Manual

- (OU01 - 21) -
Outdoor unit / Single phase
OUTDOOR UNIT WO

A060-100LF
OUTDOOR UNIT WO

A060-100LF
MODEL

: WO

A100LFTA
FT 30°C 35°C 40°C 45°C 50°C 55°C
OT HC IP COP HC IP COP HC IP COP HC IP COP HC IP COP HC IP COP
-20°C 5.97 2.57 2.32 5.89 2.86 2.06 5.60 3.05 1.84 ― ― ― ― ― ― ― ― ―
-19°C 6.41 2.72 2.36 6.31 3.01 2.10 5.97 3.20 1.87 ― ― ― ― ― ― ― ― ―
-18°C 6.84 2.86 2.39 6.73 3.17 2.12 6.34 3.36 1.89 6.03 3.49 1.73 ― ― ― ― ― ―
-17°C 7.28 3.01 2.42 7.15 3.33 2.15 6.71 3.51 1.91 6.18 3.54 1.75 ― ― ― ― ― ―
-16°C 7.29 2.97 2.45 7.18 3.29 2.18 6.78 3.50 1.94 6.34 3.60 1.76 ― ― ― ― ― ―
-15°C 7.30 2.93 2.49 7.20 3.26 2.21 6.85 3.48 1.97 6.50 3.65 1.78 ―
― ― ― ― ―
-14°C 7.31 2.90 2.52 7.23 3.22 2.25 6.92 3.46 2.00 6.61 3.66 1.81 6.41 3.91 1.64 ― ― ―
-13°C 7.33 2.86 2.56 7.25 3.19 2.27 6.99 3.44 2.03 6.72 3.66 1.84 6.52 3.92 1.66 ― ― ―
-12°C 7.34 2.82 2.60 7.28 3.15 2.31 7.06 3.42 2.06 6.84 3.67 1.86 6.63 3.92 1.69 ― ― ―
-11°C 7.35 2.79 2.63 7.30 3.11 2.35 7.13 3.40 2.10 6.95 3.68 1.89 6.75 3.93 1.72 ― ― ―
-10°C 7.36 2.75 2.68 7.33 3.08 2.38 7.19 3.39 2.12 7.06 3.68 1.92 6.86 3.94 1.74 5.89 4.09 1.44
-9°C 7.38 2.71 2.72 7.35 3.04 2.42 7.26 3.37 2.15 7.17 3.69 1.94 6.97 3.94 1.77 6.26 4.11 1.52
-8°C 7.39 2.68 2.76 7.38 3.01 2.45 7.33 3.35 2.19 7.29 3.69 1.98 7.09 3.95
1.80 6.63 4.13 1.61
-7°C 7.40 2.64 2.78 7.40 2.97 2.49 7.40 3.33 2.22 7.40 3.70 2.00 7.20 3.95 1.82 7.00 4.15 1.69
-6°C 7.48 2.62 2.85 7.43 2.91 2.55 7.38 3.24 2.28 7.33 3.58 2.05 7.16 3.85 1.86 6.98 4.10 1.70
-5°C 7.57 2.60 2.91 7.47 2.86 2.61 7.37 3.15 2.34 7.27 3.46 2.10 7.11 3.74 1.90 6.96 4.05 1.72
-4°C 7.65 2.59 2.95 7.50 2.80 2.68 7.35 3.06 2.40 7.20 3.34 2.16 7.07 3.64 1.94 6.93 4.00 1.73
-3°C 7.73 2.57 3.01 7.53 2.75 2.74 7.33 2.97 2.47 7.13 3.22 2.21 7.02 3.54 1.98 6.91 3.95 1.75
-2°C 7.82 2.55 3.07 7.57 2.69 2.81 7.32 2.87 2.55 7.07 3.10 2.28 6.98 3.43 2.03 6.89 3.90 1.77
-1°C 7.90 2.53 3.12 7.60 2.64 2.88 7.30 2.78 2.63 7.00 2.98 2.35 6.93 3.33 2.08
6.87 3.85 1.78
0°C 7.98 2.52 3.17 7.63 2.58 2.96 7.28 2.69 2.71 6.93 2.86 2.42 6.89 3.23 2.13 6.84 3.80 1.80
1°C 8.07 2.50 3.23 7.67 2.53 3.03 7.27 2.60 2.80 6.87 2.74 2.51 6.84 3.12 2.19 6.82 3.75 1.82
2°C 8.15 2.48 3.29 7.70 2.47 3.12 7.25 2.51 2.89 6.80 2.62 2.60 6.80 3.02 2.25 6.80 3.70 1.84
3°C 8.83 2.50 3.53 8.28 2.49 3.33 7.72 2.52 3.06 7.17 2.61 2.75 7.01 2.95 2.38 6.85 3.50 1.96
4°C 9.51 2.52 3.77 8.85 2.52 3.51 8.20 2.54 3.23 7.54 2.61 2.89 7.22 2.87 2.52 6.90 3.31 2.08
5°C 10.19 2.54 4.10 9.43 2.54 3.81 8.67 2.55 3.48 7.90 2.60 3.12 7.43 2.80 2.75 6.95 3.11 2.35
6°C 10.87 2.56 4.24 10.00 2.56 3.91 9.14 2.56 3.57 8.27 2.59 3.19 7.64 2.72 2.81 7.00
2.92 2.40
7°C 10.87 2.49 4.37 10.00 2.49 4.02 9.14 2.50 3.66 8.27 2.53 3.27 7.64 2.66 2.87 7.00 2.86 2.45
8°C 10.87 2.42 4.50 10.00 2.42 4.13 9.14 2.44 3.75 8.27 2.47 3.35 7.64 2.61 2.93 7.00 2.80 2.50
9°C 10.87 2.34 4.64 10.00 2.36 4.23 9.14 2.38 3.84 8.27 2.42 3.42 7.64 2.56 2.99 7.00 2.75 2.55
10°C 10.87 2.28 4.77 10.00 2.30 4.34 9.14 2.33 3.93 8.27 2.36 3.50 7.64 2.50 3.05 7.00 2.69 2.60
11°C 10.87 2.22 4.90 10.00 2.25 4.44 9.14 2.27 4.02 8.27 2.32 3.57 7.64 2.45 3.12 7.00 2.65 2.64
12°C 10.87 2.16 5.04 10.00 2.20 4.55 9.14 2.22 4.11 8.27 2.27 3.65 7.64 2.40 3.18 7.00 2.60 2.69
13°C 10.87 2.10 5.17 10.00 2.15 4.66 9.14 2.18 4.20 8.27 2.22 3.72 7.64 2.36 3.24 7.00 2.55
2.74
14°C 10.87 2.05 5.30 10.00 2.10 4.76 9.14 2.13 4.29 8.27 2.18 3.80 7.64 2.32 3.30 7.00 2.51 2.79
15°C 10.87 2.00 5.43 10.00 2.05 4.87 9.14 2.09 4.38 8.27 2.14 3.87 7.64 2.27 3.36 7.00 2.46 2.84
16°C 10.87 1.95 5.57 10.00 2.01 4.98 9.14 2.04 4.47 8.27 2.09 3.95 7.64 2.23 3.42 7.00 2.42 2.89
17°C 10.87 1.91 5.70 10.00 1.97 5.08 9.14 2.00 4.56 8.27 2.06 4.02 7.64 2.19 3.49 7.00 2.39 2.93
18°C 10.87 1.86 5.83 10.00 1.93 5.19 9.14 1.97 4.65 8.27 2.02 4.10 7.64 2.15 3.55 7.00 2.35 2.98
19°C 10.87 1.82 5.97 10.00 1.89 5.29 9.14 1.93 4.74 8.27 1.98 4.17 7.64 2.12 3.61 7.00 2.31 3.03
20°C 10.87 1.82 6.10 10.00 1.85 5.40 9.14 1.89 4.83 8.27 1.95 4.25 7.64 2.08 3.67 7.00 2.27 3.08
21°C 10.87 1.77 6.15 10.00 1.84 5.43 9.14 1.88 4.86 8.27 1.93 4.28 7.64 2.06 3.70 7.00 2.26 3.10
22°C 10.87 1.76 6.19 10.00 1.83 5.46 9.14 1.87 4.89 8.27 1.92 4.31 7.64 2.05 3.72 7.00 2.24 3.13
23°C 10.87 1.74 6.24 10.00 1.82 5.49 9.14 1.86 4.92 8.27 1.91 4.34 7.64 2.04 3.75 7.00 2.22 3.15
24°C 10.87 1.73 6.29 10.00 1.81 5.53 9.14 1.85 4.95 8.27 1.89 4.37 7.64 2.02 3.78 7.00 2.20 3.18
25°C 10.87 1.72 6.33 10.00 1.80 5.56 9.14 1.84 4.98 8.27 1.88 4.40 7.64 2.01 3.81 7.00 2.19 3.20
26°C 10.87 1.70 6.38 10.00 1.79 5.59 9.14 1.82 5.01 8.27 1.87 4.43 7.64 1.99 3.83 7.00 2.17 3.23
27°C 10.87 1.69 6.43 10.00 1.78 5.62 9.14 1.81 5.04 8.27 1.85 4.46 7.64 1.98 3.86 7.00 2.15 3.25
28°C
10.87 1.68 6.47 10.00 1.77 5.65 9.14 1.80 5.08 8.27 1.85 4.48 7.64 1.96 3.89 7.00 2.13 3.28
29°C 10.87 1.67 6.52 10.00 1.76 5.68 9.14 1.79 5.11 8.27 1.83 4.51 7.64 1.95 3.92 7.00 2.12 3.30
30°C 10.87 1.65 6.57 10.00 1.75 5.71 9.14 1.78 5.14 8.27 1.82 4.54 7.64 1.94 3.94 7.00 2.10 3.33
31°C 10.87 1.64 6.61 10.00 1.74 5.74 9.14 1.77 5.17 8.27 1.81 4.57 7.64 1.92 3.97 7.00 2.09 3.35
32°C 10.87 1.63 6.66 10.00 1.73 5.78 9.14 1.76 5.20 8.27 1.80 4.60 7.64 1.91 4.00 7.00 2.07 3.38
33°C 10.87 1.62 6.71 10.00 1.72 5.81 9.14 1.75 5.23 8.27 1.79 4.63 7.64 1.90 4.03 7.00 2.06 3.40
34°C 10.87 1.61 6.75 10.00 1.71 5.84 9.14 1.74 5.26 8.27 1.77 4.66 7.64 1.89 4.05 7.00 2.04 3.43
35°C 10.87
1.69 6.80 10.00 1.70 5.87 9.14 1.73 5.29 8.27 1.76 4.69 7.64 1.87 4.08 7.00 2.03 3.45
FT : Flow temperature
OT : Outdoor temperature
HC : Heating capacity (kW)
IP : Input power (kW)
COP : Coefcient of performance
The values of heating capacity/power input/COP are based on measurement of EN14511 standard;
FT < 45°C : The ow rate obtained during the test at the standard rating conditions of OT 7°C and Water temp. ow/return 35°C / 30°C, 1733 l/h
FT
>
=
45°C : The ow rate obtained during the test at the standard rating conditions of OT 7°C and Water temp. ow/return 45°C / 40°C, 1439 l/h
FT = 55°C : The ow rate obtained during the test at the standard rating conditions of OT 7°C and Water temp. ow/return 55°C / 47°C, 764 l/h
Usage environment, such as operation of the heating equipment, room temperature, and controller adjustments, may cause disparities between practically determined and measured
values.
