Fujitsu WOYA080LFCA Design & Technical Manual

- (OU01 - 07) -
Outdoor unit / Single phase
OUTDOOR UNIT WO

G112-140LCTA
OUTDOOR UNIT WO

G112-140LCTA
PRODUCT INFORMATION2-4.
Product information according to Commission Delegated Regulation (EU) 813/2013
Product information is based on the average climate condition.
Model
Hydraulic unit
WSYG140DG6
WSHG140DG *1
WGYG140DG6
WGHG140DG *1
WSYG140DG6
WSHG140DG *1
WGYG140DG6
WGHG140DG *1
Outdoor unit
WOYG112LCTA
WOHG112LCTA
WOYG140LCTA
WOHG140LCTA
Air-to-water heat pump Yes
Water-to-water heat pump No
Brine-to-water heat pump No
Low-temperature heat pump No
Equipped with a supplementary heater Yes
Heat pump combination heater Yes
Temperature application °C 55
35 55 35 55 35 55 35
Rated heat output *2 Prated kW 9 11 9 11 11 13 11 13
Seasonal space heating energy efciency ƞ
s % 109 151 109 151 113 148 113 148
Declared capacity for heating for part load at indoor temperature 20 °C and outdoor temperature T
j
Tj = –7 °C Pdh kW 8.2 10.0 8.2 10.0 10.0 11.1 10.0 11.1
T
j = +2 °C Pdh kW 5.0 6.1 5.0 6.1 6.1 6.7 6.1 6.7
T
j = +7 °C Pdh kW 5.9 6.2 5.9 6.2 5.9 6.2 5.9 6.2
T
j = +12 °C Pdh kW 7.0 7.4 7.0 7.4 7.1 7.3 7.1 7.3
T
j = bivalent temperature Pdh kW 8.2 10.0 8.2 10.0 10.0 11.1 10.0 11.1
T
j = operation limit temperature Pdh kW 8.0 10.0 8.0 10.0 9.3 10.8 9.3 10.8
T
j = –15 °C (if TOL < –20 °C) Pdh kW - - - - - - - -
Bivalent temperature T
biv °C -7 -7 -7 -7 -7 -7 -7 -7
Cycling interval capacity for heating P
cych kW Not applicable
Degradation co-efcient *3 Cdh — 0.9 0.9 0.9 0.9 0.9 0.9 0.9 0.9
Declared coefcient of performance or primary energy ratio for part load at indoor temperature 20 °C and outdoor temperature T
j
Tj = –7 °C COPd — 1.88 2.56 1.88 2.56 1.88 2.45 1.88 2.45
T
j = +2 °C COPd — 2.66 3.65 2.66 3.65 2.77 3.60 2.77 3.60
T
j = +7 °C COPd — 3.76 5.34 3.76 5.34 3.89 5.37 3.89 5.37
T
j = +12 °C COPd — 4.82 6.90 4.82 6.90 5.11 6.86 5.11 6.86
T
j = bivalent temperature COPd — 1.88 2.56 1.88 2.56 1.88 2.45 1.88 2.45
T
j = operation limit temperature COPd — 1.65 2.23 1.65 2.23 1.67 2.33 1.67 2.33
T
j = –15 °C (if TOL < –20 °C) COPd — - - - - - - - -
Operation limit temperature TOL °C -10 -10 -10 -10 -10 -10 -10 -10
Cycling interval efciency
COPcyc — Not applicable
Heating water operating limit temperature
WTOL °C 60 60 60 60 60 60 60 60
Power consumption in modes other than active mode
Off mode P
OFF kW 0.008 0.008 0.008 0.008 0.008 0.008 0.008 0.008
Thermostat-off mode P
TO kW 0.022 0.045 0.022 0.045 0.025 0.072 0.025 0.072
Standby mode P
SB kW 0.012 0.012 0.012 0.012 0.012 0.012 0.012 0.012
Crankcase heater mode P
CK kW 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000
Supplementary heater
Rated heat output *2 P
sup kW 1.3 1.3 1.3 1.3 2.1 1.7 2.1 1.7
Type of energy input Electric
Other items
Capacity control Variable
Sound power level
Indoor unit L
WA dB 46 46 46 46 46 46 46 46
Outdoor unit L
WA dB 68 68 68 68 69 69 69 69
Emissions of nitrogen oxides NO
x mg/kWh Not applicable
Rated air ow rate Outdoor unit — m³/h 6200 6200 6200 6200 6200 6200 6200 6200
Declared load prole - - L L - - L L
Daily electricity consumption Q
elec kWh - - 5.300 5.300 - - 5.300 5.300
Water heating energy efciency η
wh % - - 88 88 - - 88 88
Daily fuel consumption Q
fuel kWh Not applicable
Contact details
FUJITSU GENERAL (EURO) GmbH
Werftstraße 20, D-40549 Düsseldorf, F. R. Germany
*1: Optional electrical back up heater consumption is taken into account in the performance calculation.
*2: For heat pump space heaters and heat pump combination heaters, the rated heat output Prated is equal to the design load for heating
P
designh, and the rated heat output of a supplementary heater Psup is equal to the supplementary capacity for heating sup (Tj).
*3: If Cdh is not determined by measurement then the default degradation coefcient is Cdh = 0.9.
