Fujitsu WOYA080LFCA Design & Technical Manual

- (OU01 - 18) -
Outdoor unit / Single phase
OUTDOOR UNIT WO

G112-140LCTA
OUTDOOR UNIT WO

G112-140LCTA
CAPACITY TABLES6.
HEATING CAPACITY6-1.
MODEL

: WO

G112LCTA
FT : Flow temperature
OT : Outdoor temperature
HC : Heating capacity (kW)
IP : Input power (kW)
COP : Coefcient of performance
The values of heating capacity/power input/COP are based on measurement of EN14511 standard;
FT < 45°C : The ow rate obtained during the test at the standard rating conditions of OT 7°C and Water temp. ow/return 35°C / 30°C, 1872 l/h
FT
>
=
45°C : The ow rate obtained during the test at the standard rating conditions of OT 7°C and Water temp. ow/return 45°C / 40°C, 1575 l/h
FT
>
=
55°C : The ow rate obtained during the test at the standard rating conditions of OT 7°C and Water temp. ow/return 55°C / 47°C, 829 l/h
Usage environment, such as operation of the heating equipment, room temperature, and controller adjustments, may cause disparities between practically determined and measured
values.
FT 30°C 35°C 40°C 45°C 50°C 55°C 60°C
OT HC IP COP HC IP COP HC IP COP HC IP COP HC IP COP HC IP COP HC IP COP
-25°C 5.57 3.49 1.60 5.22 3.50 1.49 4.87 3.50 1.39 4.51 3.51 1.28 4.16 3.51 1.19 – – – – – –
-24°C 7.27 4.18 1.74 6.78 4.21 1.61 6.23 4.23 1.47 5.88 4.25 1.38 6.27 5.00 1.25 – – – – – –
-23°C 8.96 4.86 1.84 8.34 4.92 1.70 7.59 4.95 1.53 7.24 4.98 1.45 6.51 5.00 1.30 – – – – – –
-22°C 9.23 4.86 1.90 8.64 4.92 1.76 7.90 4.95 1.60 7.48 4.98 1.50 6.74 5.00 1.35 5.95 5.00 1.19 – – –
-21°C 9.51 4.86 1.96 8.95 4.92 1.82 8.22 4.95 1.66 7.72 4.98 1.55 6.98 5.00 1.40 6.18
5.00 1.24 – – –
-20°C 9.78 4.86 2.01 9.26 4.92 1.88 8.53 4.95 1.72 7.96 4.98 1.60 7.22 5.00 1.44 6.41 5.00 1.28 5.64 5.00 1.13
-19°C 9.94 4.81 2.07 9.48 4.92 1.93 8.78 4.95 1.77 8.20 4.98 1.65 7.44 5.00 1.49 6.64 5.00 1.33 5.75 5.00 1.15
-18°C 10.10 4.76 2.12 9.71 4.92 1.97 9.03 4.95 1.82 8.44 4.98 1.69 7.66 5.00 1.53 6.87 5.00 1.37 5.86 5.00 1.17
-17°C 10.26 4.72 2.17 9.93 4.92 2.02 9.27 4.95 1.87 8.68 4.98 1.74 7.88 5.00 1.58 7.10 5.00 1.42 5.96 5.00 1.19
-16°C 10.42 4.67 2.23 10.16 4.92 2.07 9.52 4.95 1.92 8.92 4.98 1.79 8.10 5.00 1.62 7.33 5.00 1.47 6.07 5.00 1.21
-15°C 10.58 4.62 2.29 10.38 4.92 2.11 9.77 4.95 1.97 9.16 4.98 1.84 8.32 5.00 1.66 7.56 5.00 1.51
6.18 5.00 1.24
-14°C 10.58 4.57 2.32 10.38 4.85 2.14 9.77 4.89 2.00 9.16 4.93 1.86 8.32 4.95 1.68 7.56 4.95 1.53 6.25 4.98 1.26
-13°C 10.58 4.51 2.35 10.38 4.77 2.18 9.77 4.83 2.02 9.16 4.88 1.88 8.32 4.90 1.70 7.56 4.89 1.55 6.31 4.95 1.27
-12°C 10.58 4.46 2.37 10.38 4.70 2.21 9.77 4.76 2.05 9.16 4.83 1.90 8.32 4.84 1.72 7.56 4.84 1.56 6.38 4.93 1.29
-11°C 10.58 4.41 2.40 10.38 4.62 2.25 9.77 4.70 2.08 9.16 4.78 1.92 8.32 4.79 1.74 7.57 4.79 1.58 6.45 4.90 1.32
-10°C 10.58 4.35 2.43 10.38 4.55 2.28 9.77 4.64 2.11 9.16 4.73 1.94 8.32 4.74 1.76 7.57 4.73 1.60 6.51 4.88 1.33
-9°C 10.58 4.30 2.46 10.38 4.47 2.32 9.77 4.58 2.13 9.16 4.68 1.96 8.32 4.69 1.77 7.57 4.68 1.62 6.58 4.85
1.36
-8°C 10.58 4.24 2.50 10.38 4.40 2.36 9.77 4.51 2.17 9.16 4.63 1.98 8.32 4.63 1.80 7.57 4.62 1.64 6.64 4.83 1.37
-7°C 10.58 4.19 2.53 10.38 4.32 2.40 9.77 4.45 2.20 9.16 4.58 2.00 8.32 4.58 1.82 7.57 4.57 1.66 6.71 4.80 1.40
-6°C 10.64 4.10 2.60 10.42 4.22 2.47 9.79 4.35 2.25 9.15 4.50 2.03 8.32 4.47 1.86 7.57 4.46 1.70 6.73 4.64 1.45
-5°C 10.71 4.01 2.67 10.47 4.13 2.54 9.81 4.25 2.31 9.14 4.41 2.07 8.32 4.36 1.91 7.58 4.34 1.75 6.76 4.49 1.51
-4°C 10.77 3.92 2.75 10.51 4.03 2.61 9.82 4.15 2.37 9.12 4.33 2.11 8.32 4.25 1.96 7.58 4.23 1.79 6.78 4.33 1.57
-3°C 10.83 3.83 2.83 10.55 3.93 2.68 9.84 4.05 2.43 9.11 4.24 2.15 8.32 4.14 2.01 7.58 4.11 1.84 6.80 4.17 1.63
-2°C
10.89 3.74 2.91 10.59 3.83 2.77 9.86 3.95 2.50 9.10 4.15 2.19 8.32 4.03 2.06 7.58 4.00 1.90 6.83 4.08 1.67
-1°C 10.96 3.65 3.00 10.64 3.73 2.85 9.88 3.85 2.57 9.09 4.07 2.23 8.32 3.92 2.12 7.58 3.88 1.95 6.86 3.99 1.72
0°C 11.02 3.55 3.10 10.68 3.64 2.93 9.89 3.75 2.64 9.07 3.98 2.28 8.32 3.82 2.18 7.59 3.77 2.01 6.89 3.89 1.77
1°C 11.09 3.46 3.21 10.73 3.54 3.03 9.91 3.65 2.72 9.06 3.90 2.32 8.32 3.71 2.24 7.59 3.65 2.08 6.92 3.80 1.82
2°C 11.15 3.37 3.31 10.77 3.44 3.13 9.93 3.55 2.80 9.05 3.81 2.38 8.32 3.60 2.31 7.59 3.54 2.14 6.95 3.71 1.87
3°C 11.15 3.28 3.40 10.78 3.22 3.35 9.93 3.35 2.96 9.05 3.58 2.53 8.32 3.45 2.41 7.59 3.43 2.21 6.98 3.62 1.93
4°C 11.15 3.19
3.50 10.79 3.00 3.60 9.93 3.15 3.15 9.05 3.36 2.69 8.32 3.31 2.51 7.59 3.31 2.29 7.02 3.59 1.96
5°C 11.15 3.10 3.60 10.80 2.78 3.88 9.93 2.95 3.37 9.05 3.13 2.89 8.32 3.16 2.63 7.59 3.21 2.36 7.05 3.56 1.98
6°C 11.15 2.72 4.10 10.80 2.66 4.06 9.93 2.82 3.52 9.05 2.98 3.04 8.32 3.06 2.72 7.59 3.11 2.44 7.05 3.47 2.03
7°C 11.15 2.34 4.76 10.80 2.54 4.25 9.93 2.68 3.71 9.05 2.82 3.21 8.32 2.95 2.82 7.59 3.07 2.47 7.05 3.39 2.08
8°C 11.15 2.29 4.87 10.80 2.49 4.34 9.93 2.64 3.76 9.05 2.77 3.27 8.32 2.90 2.87 7.59 3.03 2.50 7.05 3.31 2.13
9°C 11.15 2.25 4.96 10.80 2.45 4.41 9.93 2.60 3.82 9.05 2.71 3.34 8.32 2.85 2.92 7.59 3.00 2.53 7.05 3.22 2.19
10°C 11.15 2.20 5.07 10.80
2.40 4.50 9.93 2.56 3.88 9.05 2.66 3.40 8.32 2.80 2.97 7.59 2.96 2.56 7.05 3.14 2.25
11°C 11.15 2.16 5.16 10.80 2.36 4.58 9.93 2.52 3.94 9.05 2.62 3.45 8.32 2.76 3.01 7.59 2.92 2.60 7.05 3.09 2.28
12°C 11.15 2.13 5.23 10.80 2.32 4.66 9.93 2.48 4.00 9.05 2.58 3.51 8.32 2.72 3.06 7.59 2.88 2.64 7.05 3.04 2.32
13°C 11.15 2.09 5.33 10.80 2.28 4.74 9.93 2.44 4.07 9.05 2.54 3.56 8.32 2.68 3.10 7.59 2.84 2.67 7.05 2.99 2.36
14°C 11.15 2.06 5.41 10.80 2.24 4.82 9.93 2.40 4.14 9.05 2.50 3.62 8.32 2.64 3.15 7.59 2.80 2.71 7.05 2.94 2.40
15°C 11.15 2.02 5.52 10.80 2.20 4.91 9.93 2.36 4.21 9.05 2.47 3.66 8.32 2.61 3.19 7.59 2.76 2.75 7.05 2.89 2.44
16°C 11.15 1.98 5.63 10.80 2.16 5.00
9.93 2.31 4.30 9.05 2.43 3.72 8.32 2.57 3.24 7.59 2.72 2.79 7.05 2.84 2.48
17°C 11.15 1.95 5.72 10.80 2.12 5.09 9.93 2.27 4.37 9.05 2.39 3.79 8.32 2.53 3.29 7.59 2.68 2.83 7.05 2.79 2.53
18°C 11.15 1.91 5.84 10.80 2.08 5.19 9.93 2.23 4.45 9.05 2.35 3.85 8.32 2.49 3.34 7.59 2.64 2.88 7.05 2.74 2.57
19°C 11.15 1.88 5.93 10.80 2.04 5.29 9.93 2.19 4.53 9.05 2.31 3.92 8.32 2.45 3.40 7.59 2.60 2.92 7.05 2.69 2.62
20°C 11.15 1.84 6.06 10.80 2.00 5.40 9.93 2.15 4.62 9.05 2.27 3.99 8.32 2.41 3.45 7.59 2.56 2.96 7.05 2.64 2.67
21°C 11.15 1.82 6.13 10.80 1.98 5.45 9.93 2.13 4.66 9.05 2.25 4.02 8.32 2.39 3.48 7.59 2.54 2.99 7.05 2.62 2.69
22°C 11.15 1.81 6.16 10.80 1.96 5.51 9.93 2.11
4.71 9.05 2.23 4.06 8.32 2.37 3.51 7.59 2.51 3.02 7.05 2.60 2.71
23°C 11.15 1.79 6.23 10.80 1.94 5.57 9.93 2.09 4.75 9.05 2.21 4.10 8.32 2.34 3.56 7.59 2.49 3.05 7.05 2.58 2.73
24°C 11.15 1.77 6.30 10.80 1.92 5.63 9.93 2.07 4.80 9.05 2.19 4.13 8.32 2.32 3.59 7.59 2.46 3.09 7.05 2.57 2.74
25°C 11.15 1.75 6.37 10.80 1.90 5.68 9.93 2.05 4.84 9.05 2.17 4.17 8.32 2.30 3.62 7.59 2.44 3.11 7.05 2.55 2.76
26°C 11.15 1.74 6.41 10.80 1.88 5.74 9.93 2.03 4.89 9.05 2.15 4.21 8.32 2.28 3.65 7.59 2.42 3.14 7.05 2.53 2.79
27°C 11.15 1.72 6.48 10.80 1.86 5.81 9.93 2.01 4.94 9.05 2.13 4.25 8.32 2.26 3.68 7.59 2.39 3.18 7.05 2.51 2.81
28°C 11.15 1.70 6.56 10.80 1.84 5.87 9.93 1.99 4.99 9.05
2.10 4.31 8.32 2.23 3.73 7.59 2.37 3.20 7.05 2.49 2.83
29°C 11.15 1.68 6.64 10.80 1.82 5.93 9.93 1.97 5.04 9.05 2.08 4.35 8.32 2.21 3.76 7.59 2.34 3.24 7.05 2.47 2.85
30°C 11.15 1.67 6.68 10.80 1.80 6.00 9.93 1.95 5.09 9.05 2.06 4.39 8.32 2.19 3.80 7.59 2.32 3.27 7.05 2.45 2.88
31°C 11.15 1.65 6.76 10.80 1.78 6.07 9.93 1.93 5.15 9.05 2.04 4.44 8.32 2.17 3.83 7.59 2.30 3.30 7.05 2.43 2.90
32°C 11.15 1.63 6.84 10.80 1.76 6.14 9.93 1.91 5.20 9.05 2.02 4.48 8.32 2.15 3.87 7.59 2.27 3.34 7.05 2.42 2.91
33°C 11.15 1.61 6.93 10.80 1.74 6.21 9.93 1.89 5.25 9.05 2.00 4.53 8.32 2.12 3.92 7.59 2.25 3.37 7.05 2.40 2.94
34°C 11.15 1.60 6.97 10.80 1.72 6.28 9.93 1.87 5.31 9.05 1.98 4.57
8.32 2.10 3.96 7.59 2.22 3.42 7.05 2.38 2.96
35°C 11.15 1.58 7.06 10.80 1.70 6.35 9.93 1.85 5.37 9.05 1.96 4.62 8.32 2.08 4.00 7.59 2.20 3.45 7.05 2.36 2.99
