Fujitsu WOYA080LFCA Design & Technical Manual

- (OU01 - 21) -
Outdoor unit / Single phase
OUTDOOR UNIT WO

G112-140LCTA
OUTDOOR UNIT WO

G112-140LCTA
MODEL

: WO

G140LCTA
* : OPTIONAL PARTS “Cooling kit" is necessary for cooling operation.
FT : Flow temperature
OT : Outdoor temperature
CC : Cooling capacity (kW)
IP : Input power (kW)
COP : Coefcient of performance
The values of cooling capacity/power input/COP are based on measurement of EN14511 standard;
FT < 10°C : The ow rate obtained during the test at the standard rating conditions of OT 35°C and Water temp. ow/return 7°C / 12°C, 1550 l/h
FT
>
=
10°C : The ow rate obtained during the test at the standard rating conditions of OT 35°C and Water temp. ow/return 18°C / 23°C, 2157 l/h
Usage environment, such as operation of the heating equipment, room temperature, and controller adjustments, may cause disparities between practically determined and measured
values.
FT 6 °C 7 °C 10 °C 13 °C 15 °C 18 °C 22 °C
OT CC IP COP CC IP COP CC IP COP CC IP COP CC IP COP CC IP COP CC IP COP
20 °C 8.68 2.24 3.88 9.00 2.27 3.96 9.95 2.39 4.16 10.91 2.48 4.40 11.55 2.53 4.57 12.50 2.60 4.81 13.77 2.75 5.01
21 °C 8.68 2.35 3.69 9.00 2.38 3.78 9.95 2.49 4.00 10.91 2.59 4.21 11.55 2.65 4.36 12.50 2.73 4.58 13.77 2.87 4.80
22 °C 8.68 2.46 3.53 9.00 2.49 3.61 9.95 2.59 3.84 10.91 2.69 4.06 11.55 2.76 4.18 12.50 2.86 4.37 13.77 2.99 4.61
23 °C 8.68 2.57 3.38 9.00 2.60 3.46 9.95 2.69 3.70 10.91 2.80 3.90 11.55 2.88 4.01 12.50 2.99 4.18 13.77 3.11 4.43
24 °C 8.68 2.68 3.24 9.00 2.71 3.32 9.95 2.79 3.57 10.91 2.90 3.76 11.55 2.99 3.86 12.50
3.12 4.01 13.77 3.23 4.26
25 °C 8.68 2.20 3.95 9.00 2.19 4.11 9.95 2.17 4.59 10.91 2.14 5.10 11.55 2.13 5.42 12.50 2.11 5.92 13.77 2.09 6.59
26 °C 8.68 2.31 3.76 9.00 2.31 3.90 9.95 2.29 4.34 10.91 2.26 4.83 11.55 2.25 5.13 12.50 2.24 5.58 13.77 2.22 6.20
27 °C 8.68 2.43 3.58 9.00 2.42 3.72 9.95 2.41 4.13 10.91 2.39 4.56 11.55 2.38 4.85 12.50 2.37 5.29 13.77 2.36 5.83
28 °C 8.68 2.54 3.42 9.00 2.54 3.54 9.95 2.53 3.93 10.91 2.52 4.33 11.55 2.51 4.60 12.50 2.49 5.02 13.77 2.50 5.51
29 °C 8.68 2.65 3.28 9.00 2.65 3.40 9.95 2.65 3.75 10.91 2.65 4.12 11.55 2.64 4.38 12.50 2.62 4.77 13.77 2.64 5.22
30 °C 8.68 2.77 3.13 9.00 2.77 3.25 9.95 2.77 3.59 10.91 2.77 3.94 11.55 2.76 4.18 12.50 2.75 4.55
13.77 2.77 4.97
31 °C 8.68 2.88 3.01 9.00 2.88 3.13 9.95 2.89 3.44 10.91 2.90 3.76 11.55 2.89 4.00 12.50 2.87 4.36 13.77 2.91 4.73
32 °C 8.68 3.00 2.89 9.00 3.00 3.00 9.95 3.01 3.31 10.91 3.03 3.60 11.55 3.02 3.82 12.50 3.00 4.17 13.77 3.05 4.51
33 °C 8.68 3.11 2.79 9.00 3.11 2.89 9.95 3.13 3.18 10.91 3.16 3.45 11.55 3.15 3.67 12.50 3.13 3.99 13.77 3.19 4.32
34 °C 8.68 3.23 2.69 9.00 3.23 2.79 9.95 3.25 3.06 10.91 3.28 3.33 11.55 3.27 3.53 12.50 3.25 3.85 13.77 3.32 4.15
35 °C 8.68 3.34 2.60 9.00 3.34 2.69 9.95 3.37 2.95 10.91 3.41 3.20 11.55 3.40 3.40 12.50 3.38 3.70 13.77 3.46 3.98
36 °C 8.68 3.45 2.52 9.00 3.46 2.60 9.95 3.49 2.85 10.91 3.54 3.08 11.55 3.53 3.27 12.50 3.51 3.56 13.77 3.60
3.83
37 °C 8.68 3.57 2.43 9.00 3.57 2.52 9.95 3.61 2.76 10.91 3.67 2.97 11.55 3.66 3.16 12.50 3.63 3.44 13.77 3.74 3.68
38 °C 8.00 3.33 2.40 8.29 3.33 2.49 9.17 3.36 2.73 10.04 3.40 2.95 10.63 3.42 3.11 11.51 3.45 3.34 12.68 3.45 3.68
39 °C 7.74 3.34 2.32 8.02 3.34 2.40 8.88 3.36 2.64 9.73 3.40 2.86 10.30 3.42 3.01 11.15 3.44 3.24 12.29 3.45 3.56
40 °C 7.48 3.35 2.23 7.75 3.35 2.31 8.58 3.37 2.55 9.42 3.40 2.77 9.96 3.42 2.91 10.79 3.44 3.14 11.89 3.44 3.46
41 °C 7.22 3.35 2.16 7.49 3.35 2.24 8.29 3.37 2.46 9.11 3.40 2.68 9.63 3.41 2.82 10.43 3.43 3.04 11.50 3.44 3.34
42 °C 6.96 3.36 2.07 7.22 3.36 2.15 7.99 3.38 2.36 8.80 3.40 2.59 9.29 3.41 2.72 10.07 3.43 2.94 11.10 3.43 3.24
43 °C
6.70 3.37 1.99 6.95 3.37 2.06 7.70 3.38 2.28 8.49 3.40 2.50 8.96 3.41 2.63 9.71 3.42 2.84 10.71 3.43 3.12
