Fujitsu WOYA080LFCA Design & Technical Manual

- (HU01 - 03) -
Hydraulic unit / Split DHW integrated
HYDRAULIC UNIT WG

050-160DG

HYDRAULIC UNIT WG

050-160DG

SPECIFICATIONS2.
TECHNICAL SPECIFICATIONS2-1.
COMFORT SERIES

Model name (Hydraulic unit)
WGYA050DG6
WGHA050DG
WGYA100DG6
WGHA100DG
Model name (Outdoor unit)
WOYA060LFCA
WOHA060LFCA
WOYA060LFCA
WOHA060LFCA
WOYA080LFCA
WOHA080LFCA
WOYA100LFTA
WOHA100LFTA
Input power
Enclosure
Heating
Rated
kW
0.08
Max. *1 6
DHW
Rated 0.08
Max. *3 1.50
Casing
Colour White
Material 8/10mm DC01 + EZ (5µ)
Dimensions
(H x W x D)
Net
mm
1,840 x 648 x 698
Gross 2,005 x 770 x 872
Weight
Net (Empty/Full of water)
kg
WGY: 152/366, WGH: 150/364
Gross WGY: 175, WGH: 173
Main components
Pump
Type Water cooled
Speed setting Variable pressure / Constant pressure
Input power W 70 *2
Water side
Heat
exchanger
Type Double-tube
Q’ty 1
Water volume l 16
Water ow
rate Min.
l/h 490 650 810 1080
Water ow
rate Nom.
Heating
l/h
780 1040 1300 1733
Cooling 690 897 1225 1467
Insulation material polyurethane
Expansion
vessel
Volume l 12
Max. water
pressure
bar
4.0
Pre pressure 1 bar (+/-20%)
DHW tank
Type Enamel coated steel
Water volume l 190
Max.water
pressure
bar 10
Anti-corrosion Titanium anode (ACI)
Water circuit
Piping connections diameter
mm
ø25.4 (ø1 in.)
Piping ø25.4 (ø1 in.)
Safety valve bar 3
Manometer Yes
Drain valve / Fill valve Yes
Distribution valve Yes
Air purge valve Yes
DHW connection
Piping connection diameter
mm
ø19.05 (ø3/4 in.)
Piping ø19.05 (ø3/4 in.)
Connection pipe
(Refrigerant circuit)
Liquid side diameter ø6.35 (ø1/4 in.) ø9.52 (ø3/8 in.)
Gas side diameter ø12.70 (ø1/2 in.) ø15.88 (ø5/8 in.)
Method Flare
Operation range Waterside Heating °C 8 to 55
Pump rank A
*1: With electric back-up heater.
*2: The value is at Full speed and full ow.
*3: With electric DHW heater.
