Fulgor Milano Sofia Pro-Range Series - 18 Small Cavity Control Details; 30 Large Cavity Control Details

10
The user interface has the following features: display, preheat light indicators, keys for commands, cooking mode and temperature
selectors.
ELECTRONIC CONTROL (48”)
18’’ SMALL CAVITY
Signal lamp
Fan failure:
only visible on display when a problem of cooling fan system
occur.
Bake Burner ON function:
the signal lamp indicate when the flame burner turns ON, and
will switch off every time the burner turns OFF
Knobs
ONLY 18’’ SMALL CAVITY
Function selector, with four functions + OFF position.
OFF
CONV. BAKE
BAKE
DEHY.
BROIL
Thermostat selector with 170/510 ˚F temperature setting.
30’’ LARGE CAVITY
Control (only for 30’’ large cavity)
Electronic Timer
Signal lamp
Fan failure:
only visible on display when a problem of cooling fan system
occur.
Bake Burner & Broil ON function:
the signal lamp indicate when the flame burner turns ON, and
will switch off every time the burner turns OFF
Knobs
ONLY 30’’ LARGE CAVITY
Function selector, with four functions + OFF position.
OFF
CONV. BAKE
BAKE
DEHY.
BROIL
Thermostat selector with MIN/MAX temperature setting +
PIZZA function + T position.
EN
4 - The Control Panel
Bake Burner ON signal lamps
Bake Burner & Broil ON signal lamps
