OWNER’S MANUAL
308-526
Rev A
This
manual contains
IMPORTANT
WARNINGS
and
INSTRUCTIONS
READ AND RETAIN FOR REFERENCE
FULLER
O’BRIEN PRO
3515, 4020, 4030
Pressure W
ashers
PRO
3515, 5 HP ENGINE
P/N 800–584, Series A
1500 psi (103 bar) OPERA
TING PRESSURE
1900 psi (131 bar) MAXIMUM WORKING PRESSURE
PRO 4020, 8 HP ENGINE
P/N 800–585, Series A
2000 psi (138 bar) OPERA
TING PRESSURE
2400 psi (165 bar) MAXIMUM WORKING PRESSURE
PRO 4030, 1
1 HP ENGINE
P/N 800–586, Series A
3000 psi (207 bar) OPERA
TING PRESSURE
3400 psi (234 bar) MAXIMUM WORKING PRESSURE
FULLER
O’BRIEN CORPORA
TION, 450 EAST GRAND A
VENUE, SAN FRANCISCO, CA 94080
COPYRIGHT
1990, GRACO INC.
TM
PRO 4030
PRO 3515
PRO 4020

Questions and Answers

  • R
    Ronald MartinAug 16, 2025
    How to fix a FULLER O’BRIEN Pressure Washer engine that won't start?
    • S
      Sarah FarmerAug 16, 2025
      If your FULLER O’BRIEN Pressure Washer engine won't start, first, ensure there's gasoline in the fuel tank and the fuel shut-off valve is open. If the tank is full, check the oil level and add more if it's low. Make sure the Start/Stop switch is in the Start position. Also, consider draining the fuel tank and carburetor if there's water in the gasoline or if the fuel is old, and use new fuel and dry the spark plug. If the engine is flooded, clear out the gas by opening the choke and cranking the engine several times. Also, clean or replace a dirty air filter or spark plug. Finally, ensure the spray gun is not closed by triggering it.
  • G
    Glen AliAug 19, 2025
    What to do if my FULLER O’BRIEN PRO 4030 Pressure Washer has low pressure and/or the pump runs rough?
    • S
      Shannon PrestonAug 19, 2025
      If you notice low pressure or the pump runs roughly on your FULLER O’BRIEN Pressure Washer, it could be due to several reasons. Start by checking the water flow rate to the pump to ensure there is an adequate water supply. Inspect the garden hose for any collapses or kinks that might be restricting the inlet. Clean the inlet filter, inlet and discharge valve assemblies and check the filter for any particles. Replace the high-pressure hose if it's leaking. If the tip is worn or the wrong size, replace it with a tip of the proper size. Replace worn valves and packings. If there's belt slippage, tighten or replace the belts, using correct belts and replacing both at the same time.
  • W
    wmonroeAug 22, 2025
    Why does my FULLER O’BRIEN Pressure Washer engine miss or lack power?
    • K
      Kerri RamirezAug 22, 2025
      If your FULLER O’BRIEN Pressure Washer engine misses or lacks power, start by removing and cleaning the air cleaner filter if it's partially plugged. Also, check the spark plug; if it's dirty, has the wrong gap, or is the wrong type, clean it, adjust the gap, or replace it.
  • B
    Brenda GordonAug 26, 2025
    What causes frequent or premature failure of the packings in my FULLER O’BRIEN PRO 4030?
    • A
      anthonysantiagoAug 26, 2025
      Frequent failure of the packings in your FULLER O’BRIEN Pressure Washer can be caused by several factors. Check the water temperature; it may not exceed 160F. Ensure you're not overpressurizing the pump by avoiding modifications to any factory–set adjustments. Clean or replace the tip if it's partially plugged or damaged. Never run the pump for more than 10 minutes without spraying, and do not run the pump without water. Install new plungers if the existing ones are scored, damaged, or worn. If there's abrasive material in the fluid being pumped, install proper filtration on the pump inlet plumbing.
  • W
    William FordAug 28, 2025
    What causes water leakage from under the pump manifold in my FULLER O’BRIEN PRO 4030 Pressure Washer?
    • U
      ucurtisAug 28, 2025
      If you notice water leaking from under the pump manifold of your FULLER O’BRIEN Pressure Washer, it's likely due to worn packings. To resolve this, install new packings.
  • J
    Jason MitchellAug 31, 2025
    How to deal with water in the pump of my FULLER O’BRIEN PRO 4030?
    • L
      laurenmorganAug 31, 2025
      If you find water in the pump of your FULLER O’BRIEN Pressure Washer, it could be due to humid air condensing inside the crankcase, worn packings, or leaking oil seals. Address this by changing the oil as specified in MAINTENANCE, installing new packings, and installing new oil seals.
  • K
    kelly66Sep 3, 2025
    What causes strong surging at the inlet and low pressure on the discharge side of FULLER O’BRIEN PRO 4030 Pressure Washer?
    • W
      wilsonjustinSep 3, 2025
      Strong surging at the inlet and low pressure on the discharge side of your FULLER O’BRIEN Pressure Washer is usually caused by foreign particles in the inlet or discharge valve. Clean or replace the valves to resolve this issue.
  • D
    david26Sep 6, 2025
    What to do if there is oil leakage between the gear reducer cover and case of my FULLER O’BRIEN PRO 4030?
    • L
      lawrenceemilySep 6, 2025
      If you observe oil leakage between the gear reducer cover and case of your FULLER O’BRIEN Pressure Washer, the cause is likely a worn gasket. Replace the gasket to fix this.
  • E
    Erin RichardsonSep 9, 2025
    Why is there oil leakage between the gear reducer cover and the pump in my FULLER O’BRIEN Pressure Washer?
    • C
      Christopher WestSep 9, 2025
      If you notice oil leakage between the gear reducer cover and the pump of your FULLER O’BRIEN Pressure Washer, it's likely due to worn oil seals and/or o-rings. To fix this, replace the oil seals and/or o-rings.
  • T
    Thomas TaylorSep 12, 2025
    What causes oil leakage between the gear reducer case and the engine in my FULLER O’BRIEN PRO 4030?
    • B
      Brenda MclaughlinSep 12, 2025
      If you see oil leaking between the gear reducer case and the engine of your FULLER O’BRIEN Pressure Washer, it's probably due to a worn oil seal. Replace the oil seal to stop the leakage.

Summary

Safety Warnings and Hazards

Fluid Injection and Moving Parts Risks

Dangers from high-pressure fluid injection and machine moving parts.

Spray Gun and Safety Device Precautions

Safe operation of spray gun, trigger latch, and tip handling.

Operational Safety and Standards

Equipment, Hose, Fuel, and Emission Safety

Hazards of misuse, hose integrity, fuel handling, and exhaust.

Important Safety Standards

Adherence to US government safety and construction standards.

Installation and Water Supply

Setup and Water Connection Procedures

Inspecting for damage, initial setup, and connecting to water source.

Startup Procedures

Engine and Pump Preparation

Checking oil, fuel, and water before starting the engine.

Engine Starting and Operational Cautions

Steps for starting the engine and important operational cautions.

Spray Gun and Tip Handling

Trigger Safety Latch and Spray Tip Procedures

Safe use of the trigger latch and changing spray tips.

Shutdown, Storage, and Maintenance

Shutdown, Flushing, and Storage

Procedures for safely shutting down, flushing, and storing the unit.

Maintenance Schedule and Tasks

Regular maintenance intervals and tasks for optimal performance.

Troubleshooting Common Issues

Problem Diagnosis and Solutions

A chart listing common problems, their causes, and recommended solutions.

Pressure Washer Parts Identification

PRO 3515 Parts Drawing and List

Visual and detailed component lists for the PRO 3515 model.

PRO 4020 Parts Identification

PRO 4020 Parts Drawing and List

Visual and detailed component lists for the PRO 4020 model.

PRO 4030 Parts Identification

PRO 4030 Parts Drawing and List

Visual and detailed component lists for the PRO 4030 model.

Gear Reducer Service - PRO 3515

Replacing Seals, Gaskets, and Assembly

Procedures for servicing and assembling the PRO 3515 gear reducer.

Gear Reducer Service - PRO 4020

Replacing Seals, Gaskets, and Assembly

Procedures for servicing and assembling the PRO 4020 gear reducer.

Pump Assembly Service and Parts

1500 psi Pump Assembly Service and Parts

Procedures and parts for the 1500 psi pump assembly.

2000 psi Pump Assembly Service and Parts

2000 psi Pump Assembly Service and Parts

Procedures and parts for the 2000 psi pump assembly.

3000 psi Pump Assembly Service and Parts

3000 psi Pump Assembly Service and Parts

Procedures and parts for the 3000 psi pump assembly.

Pump Service Procedures

Servicing Pump Valves and Plungers

Instructions for servicing pump valves and plungers, including kits.

Pump Component Servicing

Servicing Pumping Section and V-Packings

Procedures for servicing the pump's manifold, crankcase, and V-packings.

Accessories and Technical Data

Optional Accessories and Technical Specifications

Information on accessories and detailed technical specifications for the units.

Graco Warranty and Support

Warranty Terms, Disclaimers, and Contact Information

Details of the manufacturer's warranty, limitations, and important contact numbers.
