Servicing the V–Packings
NOTE:
There are two types of packing kits: one is
packings
only
,
the other includes the packings,
rings
and retainers.
1. Remove the manifold as outlined in the Pumping
Section.
2. Carefully
pull the packing retainer from the manifold.
Examine the o–ring and replace it if it is cut or
damaged.
3. Remove the v–packing and head ring. Pull out the
intermediate retainer ring. Remove the second
v–packing
and second head ring.
4.
Inspect all parts and replace as necessary
.
5. Thoroughly
clean the packing cavities and
examine
for
debris or damage.
6. Lightly
grease the packing cavities and then replace
the packings in the following order: head ring,
v–packing, intermediate ring, head ring, v–packing
and
packing retainer with the o–ring installed in the
retainer
groove.
CAUTION
Install the parts in the proper order and facing
the
correct direction. Improperly installed parts
will
cause a malfunction.
7. Reassemble
the manifold as instructed in Servicing
the
Plungers.
ACCESSORIES
(Must be purchased separately)
DOWNSTREAM CHEMICAL INJECT
OR KIT
800–117
For injecting harsh cleaning chemicals downstream
from
the pump.
UPSTREAM CHEMICAL INJECTOR KIT
800–257
For
injecting mild cleaning chemicals upstream into
the
pump.
BACKFLOW
PREVENT
OR 801–133
Prevent back–up of contaminated water into fresh
supply.
Install upstream of pump.
ANTI–FREEZE FLUSH KIT 802–327
For
flushing system with 50% anti–freeze solution prior
to transporting or storing pressure washer in below
freezing
temperatures.
INLET
PRESSURE REGULA
TOR 800–258
Regulates inlet water pressure to 60 psi (4 bar)
maximum.
TECHNICAL DATA
Model
800–586
Model 800–585Model 800–584
Engine
(air–cooled, 4 cycle)
Gasoline T
ank Capacity
W
ater Pump Maximum
Working Pressure
W
ater Pump Maximum Flow
Inlet Hose Connection
Weight
Dimensions
Length
Width
Height
Maximum Inlet W
ater
Temperature
W
etted Parts
High Pressure Hose
Bypass Hose
Pressure Washer
(including fittings)
5 hp Honda OHV 8 hp Honda OHV
1
1 hp Honda OHV
3.8 quarts (3.6 liter)
6.2 quarts (6 liter)
6.9 quarts (6.5 liter)
1500 psi (103 bar) 2000 psi (138 bar) 3000 psi (207 bar)
3.5 gpm (13 lpm) 4 gpm (15 lpm) 4 gpm (15 lpm)
3/4” garden hose (f) 3/4” garden hose (f) 3/4” garden hose (f)
105 lb (48 kg) 158 lb (70 kg)
219 lb (100 kg)
37” (940 mm) 36” (914 mm)
44” (1
1
18 mm)
19” (483 mm) 21” (533 mm) 31” (787 mm)
20” (508 mm)
22.5” (572 mm)
26” (660 mm)
160_ F
(70
_ C) 160_ F
(70
_ C) 160_ F
(70
_ C)
Acrylonitrile
and Buna–N cover and tube
Synthetic yarn and EPDM
Anodized aluminum, Aluminum or bronze alloys, Brass Copper
, Nylon–
r
composite,
Ceramic, Buna–N, Cotton phenolic, 303, 304, and 316 Stainless steel, Polymide–12
thermoplastic,
r
, Carbon steel, Zinc with or without yellow chromate plate
is a registered trademark of the DuPont Company
.
