FULLER O’BRIEN PRO 4030 - Page 25

25
308–526
PARTS LIST
800–327 Pump Assembly, 3000 psi
REF PART
NO. NO. DESCRIPTION QTY
1 801–467 MANIFOLD 1
2 801–468 SCREW
, Cap, hex hd 8
3 801–469 W
ASHER, Lock 8
4
KIT 1 O–RING
5
KIT 1 SEAT , V alve
6
KIT 1 PLA TE, V alve
7
KIT 1 SPRING
8
KIT 1 GUIDE, V alve
9
KIT 4 O–RING
10
KIT 4 CAP
11
KIT 1 VAL VE ASSEMBL Y
12 803–283 SCREW
, Cap, socket hd 8
13 803–284
COVER, Crankcase 1
14 802–500
O–RING, Crankcase Cover 2
15 803–285
BEARING, T apered Roller 2
16
KIT 2 SEAL, Oil
17 803–286 BUSHING, Piston 1
18 802–895 CRANKCASE 1
19 801–475 DIPSTICK 1
20 803–144 GASKET
, Cover 1
21 803–332 CRANKSHAFT 1
22 803–288
RING, Retaining 6
23 802–794 KEY 1
24 803–289
PIN, W rist 3
25 803–290
GUIDE, Piston 3
26 803–291
ROD, Connecting 3
27 803–292 SCREW
, Cap, socket hd 5
28 803–293
COVER, Crankcase, 3000 psi 1
29 802–345
GAUGE, Sight 1
30 802–793
PLUG, Oil Drain 1
31
KIT 6 O–RING
32 803–294 SCREW
, Cap, socket hd 6
33 801–652 W
ASHER, Lock 6
34 801–660 W
ASHER, Flinger 3
REF P
ART
NO. NO. DESCRIPTION QTY
35 801–490
PLUNGER, Ceramic 3
36
KIT 6 RING, Backup
37 KIT 6 WASHER
38
KIT 6 SCREW , Piston
39 803–295 COVER, Crankcase 1
40 803–296 SHIM 2
41
KIT 3 SEAL, Oil
42 KIT 28 O–RING
43
KIT 28 RET AINER, Packing
44 KIT 28, 8 PACKING
45
KIT 28 RING, Head
46 KIT 28 RET AINER, Packing
47 KIT 28 RING, Long Life
48 801–526 BRACKET , Pump 2
49 802–305 SCREW
, Cap, socket hd 2
50 802–304 W
ASHER, Lock 2
51 801–482
PLUG, Hex 1
52 801–483 W
ASHER, Flat 1
53 801–484
PLUG, Hex 1
54 801–485 W
ASHER, Flat 1
55 801–737 PUMP 1
56 803–083
LABEL, Keep From Freezing 1
57 802–085 NIPPLE 1
58 801–106 TEE 1
59 800–113 FIL
TER (see Inst. Manual
801–744) 1
60 801–111 NUT
, Garden Hose 1
61 801–110
ADAPTER, Garden Hose 1
62 801–112
STRAINER, Garden Hose 1
63 801–141
HOSE ASSEMBL Y , Bypass 1
64 803–142
NIPPLE, Hex 1/2 x 3/8 1
65 800–324
UNLOADER, 3000 psi 1
66 801–868
NIPPLE, Hex 3/8 1
67 801–568
COUPLER, Male 3/8 1
Kit
No.
Repair Kit
Part No.
Ref
No.
Description Qty.
1 801–472
Valve
4
5
6
7
8
11
O–RING
SEAT
, V alve
PLA
TE, V alve
SPRING
GUIDE, V alve
VAL
VE ASSY .
6
6
6
6
6
6
2 801–473
Oil Seal
16 SEAL, Oil 3
3 802–511
Crankshaft
Seal
41 SEAL, Oil 2
4 802–306
V
alve Cap
9
10
O–RING
CAP
6
6
Kit
No.
Repair Kit
Part No.
Ref
No.
Description Qty.
6 801–474
Plunger
Repair
31
36
37
38
O–RING
RING, Backup
WASHER
SCREW
, Piston
3
3
3
3
8 801–486
Packing
44 PACKING 6
28 801–487
Packing &
Retainer
42
43
44
45
46
47
O–RING
RET
AINER, Packing
PACKING
RING, Head
RET AINER, Packing
RING, Long Life
1
1
2
1
1
1
