SAFETY CHECKS: Check all safeties below for proper operation and document the final settings.
DEVICE SETTING OPERATIONAL
Low Water Safety
Air Switch
Low Gas Pressure Switch
High Gas Pressure Switch
Proof of Closure (POC)
Blocked Flue Switch
High Temperature Limit
Temperature Controller
Stack Temperature Limit
COMBUSTION SETTINGS: Fuel Type is: Natural Gas − Propane (Circle One)
FIRING POSITION:
Light off RPM
(Enrichment Test)
OPERATING HISTORY (R7910A SOLA)
Burner Cycles
Burner Hours
Controller Cycles
Note: Use only a Slack Tube
®
Manometer or equivalent. The use of a digital manometer is not recommended.
When complete, please keep this form with the boiler, store a record copy in a safe location, and return a copy to Fulton:
The Fulton Companies
ATTN: FHS Service Coordinator
972 Centerville Road
Pulaski, New York 13142
Phone: (315) 298-5121 • Fax: (315) 298-6390
Low Fire
(Min Modulation)
High Fire
(Max Modulation)
SOLA RPM
Supply Gas Pressure (InWC)
Main Gas Valve Inlet Pressure (InWC)
Manifold Gas Pressure (InWC)
Fan Discharge Pressure (InWC)
Flue Gas Vent Pressure (SEE NOTE) (InWC)
Damper Actuator Orange Cam (Degrees)
Without Enrichment Gas: O2%
With Enrichment Gas Service Test: O2%
CO2%
CO ppm
Boiler Room Ambient Temp. °F
Combustion Air Temp. °F
Stack Temperature °F
Enrichment Gas Valve Inlet (InWC)
Main Flame Signal
Blower Current (Amps)
Blower Voltage (Volt)
MGV Offset Position “+”, “-” or Neutral?
NOx @ 3% O2
Excess Air %
Inlet Water Temp °F
Outlet Water Temp °F
O2%
Controller Hours
DEVICE SETTING OPERATIONAL
Blower Leak Test
Fuel Train Leak Test
