FULTON Endura - Page 32

© Fulton Group N.A., Inc. 2022
INSTALLATION EDR-SOLA-IOM-2022-0216 SECTION 2
2-26
OUT TO
EXHAUST
TERMINATION
STAINLESS STEEL
EXHAUST PIPE
STAINLESS STEEL
ENDURA ADAPTOR
(CONSULT YOUR
VENTING SUPPLIER)
UPDATED ELBOW LOCATION. M.E.B. 8/18/14 N/A N/A
MEH
8/21/14
AAF
8/21/14
KDB
8/18/14
REVISION HISTORY
EV
REVISION DESCRIPTION B.O.M. ELEC. ENG MECH. ENG CHECKED APPROVED
45° REDUCING TEE
(SEE NOTE 7)
SWEEPING 90° ELBOW
(SEE NOTE 8)
UP TO TERMINATION
COMMON EXHAUST HEADER
(SEE NOTES 4,5,6)
NOTES:
1.
2.
3.
4.
5.
6.
7.
8.
9.
THIS IS A TYPICAL ARRANGEMENT FOR
REF
PURPOSES ONLY. ACTUAL INSTALLATION
S
ALTERNATE OR ADDITIONAL COMPONEN
TS
SHOWN FOR CLARITY.
THIS DRAWING IS NOT FOR CONSTRUCT
IO
REFER TO THE INSTALLATION AND OPER
AT
INFORMATION REGARDING CLEARANCES
AN
REQUIREM
ENTS.
THE COMMON EXHAUST HEADER SHOUL
D B
A SLIGHT NEGATIVE PRESSURE WITHIN
TH
OF THE BOILER. A POSITIVE PRESSURE
CO
WILL REQUIRE ACCESSORIES TO GUARA
NT
CANNOT TRAVEL BACKWARD THROUGH
AN
A CONSTANT DIAMETER COMMON HEAD
ER
DO NOT USE THE STATIC REGAIN METH
OD
A MINIMUM 1/4" RISE PER FOOT RUN IS
RE
A 45° REDUCING
TEE OR ELBOW IN THE
DI
IS RECOMMENDED. STRAIGHT OR 90° TE
ES
USED.
DO NOT USE BOOT TEES OR BULL HEAD
TE
ENDURA BOILERS CANNOT BE COMMON VE
FULTON ENDURA
HYDRONIC CONDENSING BOILER
ECCENTRIC INCREASER
PVC
EXHAUST PIPE
PVC COUPLING
CPVC
STARTER PIECE
OUT TO
EXHAUST
TERMINATION
STAINLESS STEEL
ENDURA TO
CPVC APPLIANCE
ADAPTER
(SEE TABLE 8)
(SEE TABLE 8)
FIGURE 19  ENDURA EXHAUST VENTING
FIGURE 20  ENDURA COMMON EXHAUST VENTING; TYPICAL INSTALLATION GUIDELINES
Note: All installations must
be in compliance with local
and national codes. Typical
installation diagrams in this
manual are for reference
purposes only.
