FT-C Vertical Electric Thermal Fluid Heater Manual 12 2013 ISSUE 1
a) All heaters will also require a minimum clearance overhead for coil removal. In cases where
the available height is insufcient, a roof or ceiling trap might be considered.
b) Pipes should not be run within 250 mm of any control cabinets or combustible material.
c) Failure to provide suitable and safe access at the time of commissioning may cause delays, as
our Service Engineers are instructed not to commence commissioning if hazardous conditions
exist.
a) Access around the heater should be provided to facilitate maintenance. Appropriate clearances
for all sides follow.
b) Place heater with clearances to unprotected combustible materials, including plaster or
combustible supports, not less than the following:
1
0.5
0.5
0.5
2835
3097
3180
3554
4153
4655
6005
6038
6062
6031
6851
For minimum clearances for personnel access and burner removal, refer to Technical Information
sheet for the heater.
