INSTALLATION AND

OPERATION MANUAL

Vantage (VTG)

Condensing Hydronic Boilers

Standard, Dual Fuel, and Low Emissions Models

2,000,000 - 6,000,000 BTU/HR

504k - 1.5 MM kCal/HR

Serial/ National

Board Number

Model

Fulton Order

Owner

Site Name

Date

VTG-IOM-2016-1214
