FULTON Vantage VTG 2000

Questions and Answers

M
Michele NunezAug 9, 2025
What to do if the pilot fails on my FULTON Boiler?
- T
  Thomas RamseyAug 9, 2025
  If the pilot fails on your FULTON Boiler, several factors could be at play. Start by ensuring the manual shut-off valves are open, allowing gas to flow to the pilot tube. Then, adjust the incoming gas pressure and pilot gas pressure regulator to match the start-up report. If these steps don't resolve the issue, there may be air in the pilot gas line. In that case, allow the boiler to attempt lighting up to three times. If it still fails, it is recommended to call Fulton.
M
Melanie WaltersAug 28, 2025
How to fix a FULTON Boiler when the control doesn't illuminate?
- V
  Vicki HallAug 28, 2025
  If the control panel on your FULTON Boiler isn't lighting up, it's likely a power supply issue. Check the fuse or circuit breaker and reset or replace it as needed.
C
clarkguyNov 17, 2025
Why won't the fan start on my FULTON Boiler?
- T
  Terry MarshNov 17, 2025
  If the fan on your FULTON Boiler isn't starting, there are several potential causes: * A high temperature, low gas, or high gas trip may have occurred. In this case, try resetting the switch. If that doesn't work, the switch may need replacement. * The UT32A may be incorrectly set, preventing heat. Adjust the UT32A accordingly. * The flame detector may be detecting an extraneous light source. Identify and remove the light source. If the problem persists, replace the flame detector. * The air switch may be activated when the fan is off. Try resetting the switch, and if that doesn't work, replace it. * The blower contactor might be engaged when the fan is off. If so, replace the motor contactor. * A defective gas valve proof of closure can also prevent the fan from starting. Rep...

Summary

Introduction

Warnings & Cautions

Explains the importance of observing warnings and cautions for safety.

Installation

Placement & Rigging

Provides essential guidelines for proper boiler placement and rigging.

Clearances and Serviceability

Specifies required clearances for installation and access for maintenance.

Install Water Piping

Provides guidelines for installing hydronic system water piping, including connections and components.

Meet Water Chemistry Requirements

Specifies system water chemistry requirements for boiler longevity and warranty.

Install Gas Piping

Guidelines for installing natural gas piping, including size, pressure, and testing.

Install Condensate Drain

Instructions for installing single and multiple boiler condensate drain traps.

Install #2 Fuel Oil Piping

Guidelines for installing fuel oil piping for dual fuel burners, including materials and safety.

#2 Fuel Oil Piping (For Dual Fuel Gas;Oil Burner)

Venting

Combustion Air Supply From the Boiler Room

Exhaust Venting

Venting Terminations

Electrical Connections

Operation

Perform Pre-Start-Up Inspection

Details the essential pre-startup checks for safety and proper operation.

Fill and Purge the System

Outlines the procedure for filling and purging the heating system to remove air.

Commission The Boiler

Guides the process of putting the boiler into service, including safety checks.

System Design and Boiler Operation

Steps to Enter Parameters

Adjusting Fuel;Air Curve (Natural Gas or Propane or Modulating #2 Fuel Oil)

Procedure for adjusting fuel/air curves for gas or modulating oil operation.

Adjusting Fuel;Air Curve (Multistage #2 Fuel Oil - VTG-2000 DF to VTG-4000 DF)

Procedure for adjusting fuel/air curves for multistage oil operation.

Viewing Flame Signal Intensity

Manual Control (Manual Request for Output)

Viewing Total Burner Start-ups

Viewing Total Burner Hours

Changing Modbus Address

Viewing Lockout History

Parameter Backup

Parameter Restore

Operating Temperatures and Fuel Selection

Details minimum return water temperatures required for different fuels.

Temperature Controller Instructions

SC-500 Temperature Controller Basic Programming

Yokogawa UT 32 A Basic Programming

Perform Test of Ignition Safety System

Test procedure for the ignition safety system shutdown function.

Perform Test of Low Water Cut Off

Test procedure for the low water cut-off safety control.

Perform Test of Limit Controls

Test procedure for high temperature limit controls.

Perform Test of Low Gas Pressure Switch

Test procedure for the low gas pressure switch.

Perform Test of High Gas Pressure Switch

Test procedure for the high gas pressure switch.

Maintenance

Daily Maintenance and Inspection Schedule

Lists daily tasks for boiler upkeep and inspection.

Weekly Maintenance and Inspection Schedule

Lists weekly tasks for boiler upkeep and inspection.

Monthly Maintenance and Inspection Schedule

Lists monthly tasks for boiler upkeep and inspection.

Procedure for Cleaning the Air Inlet Filter (Low Emissions Burners)

Annual Maintenance and Inspection Schedule

Comprehensive annual maintenance tasks for the boiler, performed by trained technicians.

Annual Removal and Inspection of LE Bekaert Burner

Verification of Torque Settings on Fireside Access Doors

Inspecting;Cleaning the Flue Passages

Ignition Pilot Adjustment - Dual Fuel Burners

Procedures for adjusting the ignition pilot on dual fuel burners.

Troubleshooting

Guide to diagnosing and resolving common boiler issues using provided tables.

Warranty & Parts

Standard Warranty for Fulton Vantage Hydronic Boilers

Details the warranty coverage and terms for Vantage boilers.

Parts Warranty

Conditions of Warranty

Parts (Ordering)

Operation (ModSync)

Sequence of Operations

Outlines the boiler staging logic for optimal efficiency based on load and temperature.

Screen Descriptions

System Status Screen

Hydronic “Boiler Config” Configuration Screens

System Configuration Menu

System and Scaling Screen 1

Maintenance Configuration Screen 1

Maintenance Configuration Screen 2

Sensor Configuration

BMS Configuration

Alarm Configuration

Configures alarm parameters, delays, retries, and monitoring for boiler status.

Setback Schedule

Setpoint Configuration without Outdoor Reset

Setpoint Configuration with Outdoor Reset

Configures loop setpoints based on outdoor temperature using reset curves.

Outdoor Reset Configuration

Sets up loop setpoint curves for outdoor reset functionality in ModSync mode.

Alarm Status

Displays current alarm conditions monitored by the ModSync and allows viewing history.

Lead; Lag Configuration 1

Lead; Lag Configuration 2

Lead; Lag Configuration 3

Lead; Lag Configuration 4

Maintenance (ModSync)

ModSync Alarms

Backing up the Program

Battery Replacement

Common Troubleshooting Issues

Lists common ModSync issues and their possible resolutions for quick problem-solving.

Parts and Warranty (ModSync)

ModSync Limited Warranty

Outlines the warranty terms and conditions for Synex ModSync controls.
