OPERATION VTG-IOM-2016-1214 SECTION 3
! WARNING
Non-Fulton product information is for
reference purposes only. No Fulton
document should substitute for full
review of documentation available
from the component manufacturer.
4 CAUTION
After checking controls by manual
adjustment, make sure they are always
reset to their proper settings.
Commissioning/Start up by a non-
Fulton authorized person will void the
product warranty.
Please read these instructions and
post in an appropriate place near the
equipment. Maintain in good legible
condition.
Maximum allowable working pressure
and operating temperature are 160
psig (1103 kPa) and 210 F (99 C)
respectively. Aquastats are set at 200 F
(93 C). Operating > 190 F (88 C) is not
recommended.
System Design and Boiler Operation
The Vantage boiler must be installed in an appropriately designed system per
Installation section of this manual. The boiler shall be operated/controlled
to ensure the boiler does not cycle more than 12,000 times per year and the
temperature dierential across the boiler does not exceed 100°F (56°C).
Siemens LMV36 and LMV37 Control
NOTE: Operational parameters for the LMV36 are the same as those of the
LMV37, however the LMV36 has two fuel/air proles for independent operation for
the main fuel and secondary fuel.
Operating Points on the Siemens LMV Control
Vantage boilers receive a factory Test Fire Report. This includes nine operating
points pre-programmed in the Siemens LMV control by the factory. Parameter
545 requires setup specic to job site operating conditions when the boiler is
commissioned by an authorized service technician. See Table 8.
TABLE 8 MINIMUM RETURN WATER TEMPERATURES
Normal Operation
The Siemens LMV37 system is a fully packaged burner management system,
linkageless control and rst out annunciator. When operating the Siemens LMV
systems, all changes are made through the Siemens AZL display. The left and
right arrow keys are used for scrolling through the menu and changing controller
parameters. Enter accepts the menu and parameter changes. It is possible to
return to the main menu at any time by repeatedly pressing Escape. When
running the boiler, the status of the burner is to be monitored with the Siemens
AZL display. See Figure 23.
Hydronic System Setpoint Parameter 545 Setting
Systems with setpoints greater than 100°F (38°C) 20
Systems with setpoints less than 100°F (38°C), including
those operating on an outdoor reset schedule where
the setpoint can fall below 100°F (38°C)
30
