Questions? Please Contact Your Local Manufacturer’s Representative
3-17
SECTION 3 VTG-IOM-2016-1214 OPERATION
! WARNING
All information in this manual is for
reference and guidance purposes,
and does not substitute for required
professional training, conduct,
and strict adherence to applicable
jurisdictional/professional codes and
regulations.
Non-Fulton product information is for
reference purposes only. No Fulton
document should substitute for full
review of documentation available
from the component manufacturer.
4 CAUTION
The minimum return water
temperature to the boiler is 140°F (60°C)
when ring on standard oil. Failure to
maintain this will void the warranty.
Unburned oil, unlike gas, does not leave
the combustion chamber during purge.
A temperature exceeding 120°F**
(48 C) in the boiler room may cause
premature failure of electrical
components. Provisions should
be made to maintain an ambient
temperature of 120°F** (48 C) or less
(the panel box interior should not
exceed 125°F** [51 C]).
**Pumps, PLC or ModSync panels may
require lower ambient temperatures or
additional cooling.
Temperature Controller Instructions
The Siemens LMV3 Series controls are paired with a temperature controller.
Options include the SC-500 Temperature Controller, or the Yokogawa UT 32A.
SC-500 Temperature Controller Basic Programming
` CHANGE SET POINT
1. Set Point Mode is accessed through the switch selection or BMS screen
selection.
Min. Loop Temp: Minimum setpoint temperature at which the boiler can
operate.
Max. Loop Temp: Maximum setpoint temperature at which the boiler can
operate.
SC-500 Setpoint: Boiler setpoint when SC-500 setpoint mode is selected.
` SET BOILER ON TEMPERATURE
1. From Main Menu screen, select System Cong.
2. Select Sensor Cong and set.
` SET PROPORTIONAL BAND, INTEGRAL AND DERIVATIVE VALUES
The Proportional Band, Integral, and Derivative Values are accessed via the PID
Conguration Screen.
Proportional Band: This is the percentage of change in proportion to the
dierence between setpoint (SP) and process output (PV).
Integral: The integral is a variable time period used to adjust an output.
Derivative: This variable allows the anticipation of whether the PV will
overshoot the SP, and reduces the output as needed.
Manual Reset: This value will oset the PID.
