Location
The ModSync enclosure should be located in a clean, dry environment within visual
range of the boilers. Four (4) mounting supports are provided loose in the enclosure.
Secure the supports to the enclosure and mount the ModSync in an easily accessible
area of the boiler room. The enclosure meets NEMA classification 4, enclosure
dimensions may change based on hardware configurations.
Power Supply
A 120VAC/60Hz/1PH electrical supply is required by the ModSync. The hot supply
should be connected to the 10A circuit breaker for short circuit protection. The
neutral terminal block should be connected to the corresponding N terminal block
and the ground wire to the green ground terminal block provided in the ModSync
enclosure.
Hydronic Boiler Interface
Hydronic boilers provide status feedback using contact closures and analog (4-
20mA, 0-10VDC, and 0-135ohm) signals, or through Modbus communication. Please
reference the associated electrical diagram provided with the ModSync to
determine the communication runs required between the ModSync and the
Hydronic boilers.
This manual is provided as a guide
to the correct operation and
maintenance of your equipment,
and should be read in its entirety
and be made permanently
available to the staff responsible
for equipment operation. It should
not, however be considered as a
complete code of practice, nor
should it replace existing codes or
standards which may be
applicable. Synex reserves the
right to change any part of this
installation, operation and
maintenance manual without
notice.
Do not install, operate, service, or
repair any component of this
equipment unless you are qualified
and fully understand all
requirements and procedures.
All information in this manual is for
reference and guidance purposes,
and does not substitute for
required professional training,
conduct, and strict adherence to
applicable jurisdictional
/professional codes or regulations.
