FUNAI 29D-850 - Page 51

20050808 1-17-7 HK4F8EL
SUB JACK CBA
JACK CBA
R853 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
MISCELLANEOUS
SW501 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW502 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW503 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW504 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW505 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW506 LEAF SWITCH MXS01830MVP0 SSC0101MCE03
SW507 ROTARY MODE SWITCH SSS-53MD SSR0106KB003
SW509 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW510 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW511 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW512 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
2B7 SHIELD ASSEMBLY HG470ED 0VM416072
2B8 BUSH LED(F) H3700UD 0VM409508
2B46 ROHM HOLDER H7770JD 0VM304573
A4 JACK BOARD(U27 FTZ) HE480ED 0VM203840
AC001! AC CORD PE8G2CG9G0A-057 WAE0172LW012
F001! FUSE T1.6AL/250V or PAGC20BW3162
! FUSE 50T016H 1.6A/250V PAGH20BHV162
FH001 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER DFH-001 XH01Z00RP001
FH002 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER DFH-001 XH01Z00RP001
FP562 LED DISPLAY LFU-4421-2003A NP8Z4212003A
J902 BEAD CORE ASSEMBLY HK460ED 1VSA11374
JK756 RCA JACK(YELLOW) MSP-281V42-B JXRL010LY003
JK757 RCA JACK(WHITE) MSP-281V1-B JXRL010LY005
JK758 RCA JACK(RED) MSP-281V31-A JYRL010LY002
JW001 FLAT CABLE 11P AWG26#2651/P1.25/150 WX1HC460-002
JW002 FLAT CABLE 11P AWG26#2651/P1.25/150 WX1HC460-002
PS503 PHOTO INTERRUPTER RPI-302C70 QPWZP1302C70
RS501 REMOTE RECEIVER MIM-93M9DKF or USESJRSUNT03
REMOTE RECEIVER PIC-37042LQ USESJRSKK038
T001! SWITCHING TRANSFORMER 4749 or LTT00EPKT160
! PULSE TRANS BCK-25-067D LTT00EPXB024
TP301 PCB JUMPER D0.6-P10.0 JW10.0T
TP501 PCB JUMPER D0.6-P6.0 JW6.0T
TP502 PCB JUMPER D0.6-P5.0 JW5.0T
TP506 PCB JUMPER D0.6-P5.0 JW5.0T
TP507 PCB JUMPER D0.6-P6.0 JW6.0T
TU701 TUNER UNIT TMDG2-861A UTUNPLGAL014
VR501 CARBON P.O.T. VZ067TL1 B104 PB(F) VRCB104HH014
X301 XTAL 4.433619MHz or FXC445LLN001
XTAL 4.433619MHz or 1811388
QUARTZ CRYSTAL 4.433619MHz FXC445LCHE01
X501 XTAL 12.000MHz or FXD126LDS001
QUARTS CRYSTAL 12.000000MHz FXD126LCHE01
Ref. No. Description Part No.
X502 XTAL 32.768kHz(20PPM) or FXC323LQUA01
XTAL 32.768kHz(20PPM) FXC323LDS002
Ref. No. Description Part No.
SUB JACK CBA (MCV-B)
Consists of the following
---------
CAPACITORS
C751 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C752 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
RESISTORS
R751 CHIP RES.(1608) 1/10W J 820 Ω RRXAJR5Z0821
R752 CHIP RES.(1608) 1/10W J 820 Ω RRXAJR5Z0821
MISCELLANEOUS
JK751 RCA JACK 2P MSP-282V-12 NILF(B11 or JXRL020LY121
RCA JACK MSP-282V-12NILF JXRL030LY011
JW003 FLAT CABLE 3P AWG26#2651/P2.0/200 WX1HE480-001
Ref. No. Description Part No.
JACK CBA (MCV-C)
Consists of the following
----------
CAPACITORS
C101 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C102 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C103 CHIP CERAMIC CAP.(1608) CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C104 CHIP CERAMIC CAP.(1608) CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C105 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C107 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C108 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C109 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C110 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C111 CHIP CERAMIC CAP.(1608) CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C112 CHIP CERAMIC CAP.(1608) CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C113 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C115 ELECTROLYTIC CAP. 100µF/16V M H7 CE1CMAVSL101
C116 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C117 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
DIODES
D101 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D102 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D103 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D105 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
COILS
L101 BEAD CORE ASSEMBLY HK460ED 1VSA11375
L102 BEAD CORE ASSEMBLY HK460ED 1VSA11375
TRANSISTORS
Q101 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) or QQS12SA1015F
TRANSISTOR KTA1266(GR) or NQS40KTA1266
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
Q102 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) or QQS12SA1015F
TRANSISTOR KTA1266(GR) or NQS40KTA1266
Ref. No. Description Part No.
