FUNAI 29D-850 - Page 52

20050808 1-17-8 HK4F8EL
SENSOR CBA
AFV CBA
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
RESISTORS
R101 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R103 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R104 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R106 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R108 CARBON RES. 1/4W J 68 Ω RCX4JATZ0680
R109 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R110 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R112 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R113 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R115 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R116 CARBON RES. 1/6W J 15k Ω or RCX6JATZ0153
CARBON RES. 1/4W J 15k Ω RCX4JATZ0153
R117 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R118 CARBON RES. 1/4W J 68 Ω RCX4JATZ0680
R119 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R120 CARBON RES. 1/6W J 680 Ω or RCX6JATZ0681
CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R123 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R125 CARBON RES. 1/6W J 680 Ω or RCX6JATZ0681
CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R126 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R127 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
2L022 SCREW P-TIGHT M3X10 WASHER HEAD+ or GCMP3100
SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
A5 JACK BOARD(2-21P) HE470ED 0VM203835
JK101 RGB CONNECTOR MRC-021V-01 ABS(B110 or JXGL210LY007
RGB CONNECTOR MRC-021V-01 JXGL210LY002
JK102 RGB CONNECTOR MRC-021V-01 ABS(B110 or JXGL210LY007
RGB CONNECTOR MRC-021V-01 JXGL210LY002
Ref. No. Description Part No.
SENSOR CBA
Consists of the following
0VSA14893
TRANSISTORS
Q504 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q505 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Description Part No.
AFV CBA
Consists of the following
1VSA11323
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C4 CHIP CERAMIC CAP. CH J 56pF/50V or CHD1JJ3CH560
CHIP CERAMIC CAP. CG J 56pF/50V CHD1JJ3CG560
C5 CHIP CERAMIC CAP.(1608) CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C6 CHIP CERAMIC CAP. CH J 56pF/50V or CHD1JJ3CH560
CHIP CERAMIC CAP. CG J 56pF/50V CHD1JJ3CG560
C7 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
Ref. No. Description Part No.
C8 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C12 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C15 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C16 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C17 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C20 ELECTROLYTIC CAP. 3.3µF/50V M H7 CE1JMASSL3R3
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C22 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C24 ELECTROLYTIC CAP. 0.22µF/50V M H7 CE1JMASSLR22
CONNECTOR
CN1 ANGLE PIN HEADER 9P IMSA-6029B-1-
09Z003-
JTED009ER045
DIODES
D2 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
IC
IC1 IC AUDIO PROCESSOR MSP3417G-QG-B8-V3 NSZBA0SP3005
COILS
L1 INDUCTOR 10µH-K-26T LLAXKATTU100
L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH-K-26T LLAXKATTU180
L4 INDUCTOR 10µH-K-26T LLAXKATTU100
RESISTORS
R1 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R4 CHIP RES.(1608) 1/10W J 120k Ω RRXAJR5Z0124
R5 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
X1 XTAL 18.432MHz FXD186LLN001
Ref. No. Description Part No.
