20060509 1-16-1 HM456CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1X FRONT ASSEMBLY HK4F5ED 1VM220584
A2 CASE TOP(ANTHRACITE) HE240ED 0VM101267
A3 CHASSIS(U27F-GMBH) HE240ED 0VM000177D
A7 BOTTOM PANEL HK47PED 1VM321769
A10! RATING LABEL HM456ED ----------
A14 LABEL SERIAL NO. HE240ED or ----------
BARCODE LABEL HM456ED ----------
A19 LABEL SHOW VIEW H6745EP ----------
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E0FL
2B5 SHEILD CYLINDER HG470ED 0VM306638
2B9 CUSHION HC460ED 0VM413251
2B18 FIBER TOP CASE HC460ED 0VM412906
2L011 SCREW P-TIGHT 3X10 BIND HEAD+ GBCP3100
2L012 SCREW P-TIGHT 3X10 BIND HEAD+ GBCP3100
2L021 SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
2L031 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L041 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L042 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L051 SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
2L099 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
PACKING
S1 GIFT BOX CARTON HM456ED 1VM323048
S2 STYROFOAM HG470ED 0VM204516
S3 UNIT BAG V4010PA 0VM406453B
ACCESSORIES
X1 REMOTE CONTROL UNIT NA990ED NA990ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY R6UW/2S or XB0M311MS001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5795ED 0VM416059
X20A! OWNERS MANUAL(EN) HM456ED 1VMN22874
X20B! OWNERS MANUAL(DE) HM456ED 1VMN22875
