FUNAI 31A-664 - Page 54

20060509 1-17-9 HM456EL
SENSOR CBA
AFV CBA
CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R126 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R127 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
2L022 SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
A5 JACK BOARD(2-21P) HE470ED 0VM203835
JK101 RGB CONNECTOR MRC-021V-01 ABS(B110 JXGL210LY007
JK102 RGB CONNECTOR MRC-021V-01 ABS(B110 JXGL210LY007
Ref. No. Description Part No.
SENSOR CBA
Consists of the following:
0VSA14893
TRANSISTORS
Q504 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q505 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Description Part No.
AFV CBA
Consists of the following:
1VSA14123
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C4 CHIP CERAMIC CAP. CH J 56pF/50V CHD1JJ3CH560
C5 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C6 CHIP CERAMIC CAP. CH J 56pF/50V CHD1JJ3CH560
C7 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C8 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C12 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSM100
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C15 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSM100
C16 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSM100
C17 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C20 ELECTROLYTIC CAP. 3.3µF/50V M H7 or CE1JMASSL3R3
ALUMINUM ELECTROLYTIC CAP 3.3µF/50V
H7
CE1JMASSM3R3
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C22 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSM100
C24 ELECTROLYTIC CAP. 0.22µF/50V M H7 or CE1JMASSLR22
ALUMINUM ELECTROLYTIC CAP 0.22µF/50V
H7
CE1JMASSMR22
C26 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C27 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
CONNECTOR
CN1 ANGLE PIN HEADER 9P IMSA-6029B-1-
09Z003-
JTED009ER045
DIODES
D2 SWITCHING DIODE 1N4148M or NDTZ01N4148M
Ref. No. Description Part No.
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
IC
IC1 IC AUDIO PROCESSOR MSP3407G-QG-B8-V3 NSZBA0SP3004
COILS
L1 INDUCTOR 10µH-K-26T LLAXKATTU100
L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH-K-26T LLAXKATTU180
L4 INDUCTOR 10µH-K-26T LLAXKATTU100
RESISTORS
R1 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R4 CHIP RES. 1/10W J 120k Ω or RRXAJR5Z0124
RES CHIP 1608 1/10W J 120k Ω RRXA124YF002
R5 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R6 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
X1 XTAL 18.432MHz FXD186LLN001
Ref. No. Description Part No.
