FUNAI DR-D2831 - Cabinet Disassembly Instructions

1-5-1 E68C9DC
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps to gain
access to item(s) to be serviced. When reassembling,
follow the steps in reverse order. Bend, route, and
dress the cables as they were originally.
2. Disassembly Method
Note:
(1) Identification (location) No. of parts in the figures
(2) Name of the part
(3) Figure Number for reference
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
P = Spring, L = Locking Tab, S = Screw,
CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5) Refer to “Reference Notes.”
Reference Notes
1. CAUTION 1: Locking Tabs (L-1) and (L-2) are
fragile. Be careful not to break them.
[1] Top Cover
[8] Fan Cover
[9] Fan
[2] Front Assembly
[3] DVD Mechanism & DVD Main CBA Assembly
[4] SW CBA
[5] PCB Holder
[6] Power Supply CBA
[7] Power Holder
[10] Rear Panel
[11] AV CBA
[12] Jack CBA [13] AFV CBA
ID/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Desolder
Note
[1] Top Cover D1 7(S-1) ---
[2]
Front
Assembly
D2 *6(L-1), *3(L-2) 1
[3]
DVD
Mechanism &
DVD Main CBA
Assembly
D3
4(S-2), *CN501,
*CN601
---
[4] SW CBA D4 (S-3), Desolder ---
[5] PCB Holder D4 2(S-4) ---
[6]
Power Supply
CBA
D4 2(S-5), *CN1201 ---
[7] Power Holder D4 (S-6) ---
[8] Fan Cover D5 2(S-7) ---
[9] Fan D5 Fan Earth, *CN1202 ---
[10] Rear Panel D5
(S-8), 5(S-9),
2(S-10)
---
[11] AV CBA D6 3(S-11) ---
[12] Jack CBA D6 Desolder ---
[13] AFV CBA D6 Desolder ---
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
