FUNAI DR-D2831 - Electrical Parts List

20050928 1-17-1 E68C9EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
AV ASSEMBLY
AV CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
N78GYBEN
Ref. No. Description Part No.
AV ASSEMBLY
Consists of the following:
1VSA11470
AV CBA (SUB-A)
SW CBA (SUB-B)
----------
----------
Ref. No. Description Part No.
AV CBA (SUB-A)
Consists of the following:
----------
CAPACITORS
C1205 ELECTROLYTIC CAP. 3.3µF/50V M or CE1JMASDL3R3
ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASTL3R3
C1208 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1209 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1210 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1211 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1212 ELECTROLYTIC CAP. 3.3µF/50V M or CE1JMASDL3R3
ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASTL3R3
C1214 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1215 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1216 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1217 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1218 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1219 CHIP CERAMIC CAP. CH J 18pF/50V or CHD1JJ3CH180
CHIP CERAMIC CAP. CG J 18pF/50V CHD1JJ3CG180
C1220 CHIP CERAMIC CAP.(1608) CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C1222 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTL221
C1223 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
If C1225 is 0.015µF, then IC1206 is BU4219G-TR, R3112N191A-TR-FA or
R3112N191A-TR-FB.
C1225 CHIP CERAMIC CAP.(1608) B K 0.015µF/50V CHD1JK30B153
IC1206 RESET IC BU4219G-TR or QSZBA0TRM090
VOLTAGE DETECT R3112N191A-TR-FA or QSZBA0TRC021
VOLTAGE DETECT R3112N191A-TR-FB QSZBA0TRC022
If C1225 is 0.1µF, then IC 1206 is IC-PST3619NR.
C1225 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
IC1206 SYSTEM RESET IC IC-PST3619NR QSZBA0TMM151
C1228 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1229 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C1230 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C1231 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1235 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C1238 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C1239 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1241 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1242 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1244 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1245 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1246 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1247 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1248 ELECTROLYTIC CAP. 22µF/16V M or CE1CMASDL220
ELECTROLYTIC CAP. 22µF/16V M CE1CMASTL220
C1250 ELECTROLYTIC CAP. 3.3µF/50V M or CE1JMASDL3R3
ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASTL3R3
C1251 CHIP CERAMIC CAP.(1608) CH J 100pF/50V or CHD1JJ3CH101
CHIP CERAMIC CAP.(1608) CG J 100pF/50V CHD1JJ3CG101
C1252 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1256 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101
C1259 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C1260 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1261 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101
C1262 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101
C1263 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1264 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1267 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
Ref. No. Description Part No.
