FUNAI DR-D2831 - Waveforms

WAVEFORMS
1-11-1
E6820WF
WF7
AUDIO(L)-OUT
Pin 17 of CN1204
1V 0.1 µ sec
WF1 Pin 1 of CN1204
WF3 C1407 PLUS LEAD
WF4
VIDEO-G
Pin 7 of CN1204
0.2V 20 µ sec
WF5
VIDEO-B
Pin 5 of CN1204
0.2V 20 µ sec
WF6
VIDEO-R
Pin 3 of CN1204
0.2V 20 µ sec
SPDIF 1V 0.1
µ sec
WF8 Pin 1 of CN1203
WF2 Pin 9 of CN1204
VIDEO-Y 0.2V 20 µ sec
VIDEO-C 0.2V 20
µ sec
VIDEO-CVBS 0.5V 20
µ sec
NOTE:
Input: COLOR BAR SIGNAL
(WITH 1KHz AUDIO SIGNAL)
