1-10-19
WF4
PIN 7 OF
CN1204
WF2
PIN 9 OF
CN1204
WF3
C1407
PLUS LEAD
WF7
PIN 17 OF
CN1204
WF5
PIN 5 OF
CN1204
WF6
PIN 3 OF
CN1204
WF1
PIN 1 OF
CN1204
WF8
PIN 1 OF
CN1203
BE6800F01013A
AV CBA Bottom View
