20070608 1-20-14 E9G01EL
REAR JACK CBA
AFV CBA
CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R1023 CARBON RES. 1/6W G 2.2k Ω or RCX6GATZ0222
CARBON RES. 1/4W G 2.2k Ω RCX4GATZ0222
R1024 CARBON RES. 1/6W J 68k Ω or RCX6JATZ0683
CARBON RES. 1/4W J 68k Ω RCX4JATZ0683
R1025 CARBON RES. 1/6W G 5.6k Ω or RCX6GATZ0562
CARBON RES. 1/4W G 5.6k Ω RCX4GATZ0562
R1029 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1032 CARBON RES. 1/6W J 2.2k Ω or RCX6JATZ0222
CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1035 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1036 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1037 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103
CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1038 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1039 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474
CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1040 CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R1041 CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R1043 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7ZU001
METAL OXIDE FILM RES. 1W J 2.7 Ω RN012R7DP003
R1058 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1059 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1126 CARBON RES. 1/6W J 33k Ω or RCX6JATZ0333
CARBON RES. 1/4W J 33k Ω RCX4JATZ0333
MISCELLANEOUS
2B18 HEAT SINK E6800ED 1VM420987
2L019 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
AC1001! AC CORD W/O A GND WIRE BS 1800MM
BLACK
WAB0182LW019
F1001! FUSE TIME RAG FSL250V1.6A(EM) or PDGJAB0NG162
! FUSE T1.6AL/250V or PAGC20BW3162
! FUSE 50T016H 1.6A/250V PAGH20BHV162
FH1001 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
FH1002 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
JW1001 WIRE ASSEMBLY 34PIN FFC 34PIN/105MM WX1E9G00-001
T0011! TRANS POWER 7717 or LTT2PE0KT023
! TRANS POWER BCK-28-9953 LTT2PE0XB021
Ref. No. Description Part No.
REAR JACK CBA (PSV-B)
Consists of the following:
----------
CAPACITORS
C2003 CERAMIC CAP.(AX) B K 2200pF/50V CA1J222TU011
C2004 CERAMIC CAP.(AX) B K 2200pF/50V CA1J222TU011
C2005 CERAMIC CAP.(AX) B K 2200pF/50V CA1J222TU011
C2006 CERAMIC CAP.(AX) B K 2200pF/50V CA1J222TU011
C2007 CERAMIC CAP.(AX) B K 2200pF/50V CA1J222TU011
C2008 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C2009 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C2010 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C2011 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C2012 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C2013 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
DIODES
D2001 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
Ref. No. Description Part No.
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2002 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2003 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2004 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2005 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2006 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2007 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2008 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2009 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2010 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
COIL
L2001 BEAD CORE ASSEMBLY E9GA0BD 1VSA15813
TRANSISTORS
Q2002 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q2003 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
RESISTORS
R2003 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2004 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2005 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2006 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2007 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2008 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2009 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2010 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2011 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2012 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R2013 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
MISCELLANEOUS
2B60 21P EARTH PLATE E7B20ED 1VM423185
JK2001 RGB CONNECTOR MRC-021V-03 ABS(B11 JXGL210LY006
JW2001 WIRE ASSEMBLY FLAT CABLE 14P
AWG26#2561/P2.0/65
WX1E9G00-003
Ref. No. Description Part No.
AFV CBA
Consists of the following:
1VSA15656
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
Ref. No. Description Part No.
To Next Page
