FUNAI DRVR-B778S - Page 103

20070608 1-20-15 E9G01EL
C4 CHIP CERAMIC CAP. CH J 56pF/50V CHD1JJ3CH560
C5 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C6 CHIP CERAMIC CAP. CH J 56pF/50V CHD1JJ3CH560
C7 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C8 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C12 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE09
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C15 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE09
C16 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE09
C17 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C20 ELECTROLYTIC CAP. 3.3µF/50V M H7 or CE1JMASSL3R3
CAP ELECTROLYTIC 3.3µF/50V/M/H7 CA1J3R3ENE09
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C22 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMASSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE09
C24 ELECTROLYTIC CAP. 0.22µF/50V M H7 or CE1JMASSLR22
CAP ELECTROLYTIC 0.22µF/50V/M/H7 CA1JR22ENE09
C27 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
CONNECTOR
CN1 ANGLE PIN HEADER 9P IMSA-6029B-1-
09Z003-
JTED009ER045
DIODES
D2 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
IC
IC1 IC AUDIO PROCESSOR MSP3417G-QG-B8-V3 NSZBA0SP3005
COILS
L1 INDUCTOR 10µH-K-5FT LLARKBSTU100
L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH-K-26T LLAXKATTU180
L4 INDUCTOR 10µH-K-5FT LLARKBSTU100
RESISTORS
R1 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R4 CHIP RES. 1/10W J 120k Ω or RRXAJR5Z0124
RES CHIP 1608 1/10W J 120k Ω RRXA124YF002
R5 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R6 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
X1 XTAL 18.432MHz or FXD186LLN001
RESONATOR XTAL 186 910A018432-1030300 FXD186LXGE01
Ref. No. Description Part No.
