FUNAI DRVR-B778S - Page 92

20070608 1-20-4 E9G01EL
C1616 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
CAP ELECTROLYTIC 470µF/6.3V/M CA0K471ENE12
C1617 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C1618 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
CAP ELECTROLYTIC 470µF/6.3V/M CA0K471ENE12
C1619 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1620 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1621 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
CAP ELECTROLYTIC 10µF/50V/M CA1J100ENE12
C1623 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1626 CHIP CERAMIC CAP. F Z 0.22µF/16V CHD1CZ30F224
C1627 CHIP CERAMIC CAP. F Z 0.22µF/16V CHD1CZ30F224
C1628 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1629 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1630 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1631 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1632 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1633 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1634 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1635 ELECTROLYTIC CAP. 0.33µF/50V M or CE1JMASDLR33
CAP ELECTROLYTIC 0.33µF/50V/M CA1JR33ENE12
C1636 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
CAP ELECTROLYTIC 100µF/6.3V/M CA0K101ENE12
C1637 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1639 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1640 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1643 ELECTROLYTIC CAP. 47µF/6.3V M or CE0KMASDL470
CAP ELECTROLYTIC 47µF/6.3V/M CA0K470ENE12
C1645 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C1648 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1649 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1651 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C1655 CHIP CERAMIC CAP. CH J 12pF/50V CHD1JJ3CH120
C1657 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1658 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1659 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1660 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1661 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1662 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1663 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C1664 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1665 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1671 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1672 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1673 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
CAP ELECTROLYTIC 47µF/16V/M CA1C470ENE12
C1675 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
CAP ELECTROLYTIC 47µF/25V/M CA1E470ENE12
C1677 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1680 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1681 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1684 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1685 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1686 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1687 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
Ref. No. Description Part No.
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1688 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1689 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1691 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C1692 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
CAP ELECTROLYTIC 470µF/6.3V/M CA0K471ENE12
C1693 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
CAP ELECTROLYTIC 470µF/6.3V/M CA0K471ENE12
C1694 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1695 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1696 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
CAP ELECTROLYTIC 1µF/50V/M CA1J1R0ENE12
C1697 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1698 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
CAP ELECTROLYTIC 4.7µF/25V/M CA1E4R7ENE12
C1699 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C1700 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1701 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE10
C1702 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE10
CONNECTORS
CN1503 PH CONNECTOR (WHITE) TOP 2P B2B-PH-K-
S(LF)
J3PHC02JG017
CN1504 CONNECTOR FFC 34P IMSA-9615S-34A-PP-A JC96J34ER007
CN1505 FE CONNECTOR TOP 8P 08FE-BT-VK-N JCFEJ08JG001
CN1506 AFV PCB ASSEMBLY E3B01BD E3B01AFV
DIODES
D301 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D502 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D503 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D509 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D510 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D511 ZENER DIODE MTZJT-777.5A or QDTA0MTZJ7R5
DIODE ZENER 7V5BSA-T26 or NDTA7R5BST26
ZENER DIODE DZ-7.5BSAT265 NDTA0DZ7R5BS
D512 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D555 LED MIE-534A2 or NPZZM1E534A2
LED SIR-563ST3F P or QPQPS1R563ST
LED SIR-563ST3F Q QPQQS1R563ST
D1501 DIODE 1N5397-B or NDLZ001N5397
DIODE RECTIFIER IN5397 or NDLZ01N5397S
DIODE 1N5397BD NDL1001N5397
D1502 DIODE 1N5397-B or NDLZ001N5397
DIODE RECTIFIER IN5397 or NDLZ01N5397S
DIODE 1N5397BD NDL1001N5397
D1503 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1506 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
DIODE SCHOTTKY SB140 or NDLZ00SB140S
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1507 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
Ref. No. Description Part No.
