FUNAI DRVR-B778S - Page 93

20070608 1-20-5 E9G01EL
D1508 ZENER DIODE MTZJT-774.3C or QDTC0MTZJ4R3
DIODE ZENER 4V3BSC-T26 or NDTC4R3BST26
ZENER DIODE DZ-4.3BSCT265 NDTC0DZ4R3BS
D1511 ZENER DIODE MTZJT-7710B or QDTB00MTZJ10
DIODE ZENER 10BSB-T26 or NDTB010BST26
ZENER DIODE DZ-10BSBT265 NDTB00DZ10BS
D1512 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1513 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1516 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1517 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1518 ZENER DIODE MTZJT-7718B or QDTB00MTZJ18
DIODE ZENER 18BSB-T26 or NDTB018BST26
ZENER DIODE DZ-18BSBT265 NDTB00DZ18BS
D1519 ZENER DIODE MTZJT-7711B or QDTB00MTZJ11
DIODE ZENER 11BSB-T26 or NDTB011BST26
ZENER DIODE DZ-11BSBT265 NDTB00DZ11BS
D1521 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1523 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
ZENER DIODE DZ-5.6BSBT265 NDTB0DZ5R6BS
D1525 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1526 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1528 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1529 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1531 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1532 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1534 ZENER DIODE MTZJT-7733B or QDTB00MTZJ33
DIODE ZENER 33BSB-T26 or NDTB033BST26
ZENER DIODE DZ-33BSBT265 NDTB00DZ33BS
D1535 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1537 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1538 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1539 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1540 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1542 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
Ref. No. Description Part No.
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1548 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1549 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
ICS
IC301 IC Y/C/A LA71750EM-MPB-E QSZBA0RSY020
IC451 IC HIFI LA72648M-MPB-E QSZBA0RSY033
IC501 IC SYSCON M3776AMCH-AG1GP QSZAA0RHT150
IC612 VFD DRIVER IC PT6315(L) NSZBA0RG2009
IC1501 IC SWITCH 4052L-S16-R/SOP-16 or NSZBA0TUTC03
IC SWITCH HCF4052M013TR/SOP/16 or NSZBA0TSS301
IC SWITCHING CD4052BNSR or NSZBA0TTY091
IC SWITCHING TC4052BF(ELNF) QSZBA0TTS162
IC1504 VOLTAGE REGULATOR PQ070XF01SZH or QSZBA0SSH054
IC VOLTAGE REGULATOR PQ070XFC1SZF /
4PIN
QSZBA0RSH083
IC1505 VOLTAGE REGULATOR PQ070XF01SZH or QSZBA0SSH054
IC VOLTAGE REGULATOR PQ070XFC1SZF /
4PIN
QSZBA0RSH083
IC1506 IC OP AMP UTC4580 DIP-8 8PIN or NSZBA0S2H003
IC OP AMP RC4580IP NSZBA0STY173
IC1507 VIDEO SWITCH MM1697AJBE QSZBA0TMM150
IC1508 IC SWITCH 4053L-S16-R or NSZBA0TUTC04
IC ANALOG MULTIPLEXERS
HCF4053M013TR or
NSZBA0SSS002
IC ANALOG MULTIPLEXER CD4053BNSR or NSZBA0TTY093
IC SWITCH TC4053BF(EL N F) QSZBA0TTS163
IC1509 IC SWITCH 4053L-S16-R or NSZBA0TUTC04
IC ANALOG MULTIPLEXERS
HCF4053M013TR or
NSZBA0SSS002
IC ANALOG MULTIPLEXER CD4053BNSR or NSZBA0TTY093
IC SWITCH TC4053BF(EL N F) QSZBA0TTS163
IC1510 IC SWITCH 4053L-S16-R or NSZBA0TUTC04
IC ANALOG MULTIPLEXERS
HCF4053M013TR or
NSZBA0SSS002
IC ANALOG MULTIPLEXER CD4053BNSR or NSZBA0TTY093
IC SWITCH TC4053BF(EL N F) QSZBA0TTS163
IC1511 IC VPS/PDC SLICER LC74793NJM-TLM-E QSZBA0TSY049
IC1513 IC OP AMP KIA4558P/P or NSZBA0SJY035
IC OP AMP UTC4558 NSZBA0S2H001
IC1514 DRIVER FOR DVD MM1637XVBE QSZBA0TMM102
IC1515 DRIVER FOR DVD MM1636XWRE QSZBA0TMM108
IC1516 DRIVER FOR DVD MM1637XVBE QSZBA0TMM102
IC1518 AV SWITCH MM1443XJBE QSZBA0TMM152
COILS
L251 INDUCTOR 5.6µH-K-26T LLAXKATTU5R6
L302 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L402 INDUCTOR 47µH-K-5FT LLARKBSTU470
L451 INDUCTOR 47µH-K-5FT LLARKBSTU470
L452 PCB JUMPER D0.6-P5.0 JW5.0T
L501 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L502 PCB JUMPER D0.6-P5.0 JW5.0T
L503 INDUCTOR 1.8µH-K-26T LLAXKATTU1R8
L1501 RADIAL TYPE CHOKE COIL CW68-470K-
841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
L1503 PCB JUMPER D0.6-P5.0 JW5.0T
L1504 PCB JUMPER D0.6-P5.0 JW5.0T
L1505 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1506 PCB JUMPER D0.6-P5.0 JW5.0T
L1507 RADIAL TYPE CHOKE COIL CW68-470K-
841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
Ref. No. Description Part No.
