FUNAI LC5-D20BB - Mechanical Parts List

20070911 12-1 A7340CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1 FRONT CABINET L4624FE 1EM121821
A3 CONTROL PLATE L4520EA 1EM322201
A4 REAR CABINET A7340EP 1EM021783
A7 FUNCTION KNOB L4520EA 1EM322200
A8 FRONT PLATE A7343FP 1EM221642
A9 STAND COVER A7141UH 1EM021703
A10 CONNECTOR CAP A7340EP 1EM424510
A12 STAND RUBBER FOOT L4300UA 1EM422534
B1 SPEAKER HOLDER A7120UH 1EM423986
B2 TILT STAND HOLDER A7140UH 1EM322402
B3 STAND HOLDER L2500UA 1EM321428
B4 JACK HOLDER A7340EP 1EM322697
B8 ARM ASSEMBLY A7140UH 1EM221550
B14 CLOTH(10X180XT0.5) L0336JG 0EM408827
B15 CLOTH 10X150XT1.0 1EM421092
B22 CLOTH(10X90XT1.0) A7120UH 1EM424258
L2 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L3 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L6 SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
L20 SCREW B-TIGHT M4X8 BIND HEAD+ BLK GBHB4080
Ref. No. Description Part No.
A6! RATING LABEL A7340EP ----------
L4 SCREW P-TIGHT 3X12 BIND HEAD+ BLK GBHP3120
L5 SCREW P-TIGHT M4X18 BIND HEAD+ GBHP4180
L6 SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
L8 SCREW P-TIGHT 3X14 WASHER HEAD+ GCJP3140
L11 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L12 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L18 DOUBLE SEMS SCREW M4X12 + BLAK FPH34120
SP801 SPEAKER S0407F10 or DSD0807XQ002
SPEAKER MAGNETIC YDP47-1FN DSD0807EFU01
SP802 SPEAKER S0407F10 or DSD0807XQ002
SPEAKER MAGNETIC YDP47-1FN DSD0807EFU01
PACKING
S1 CARTON A7340EP 1EM424654
S2 STYROFOAM TOP A7340EP 1EM021817
S3 STYROFOAM BOTTOM A7340EP 1EM021818
S4 SET BAG L0301UB 1EM320014B
S5 SERIAL NO. LABEL L9750UA ----------
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2-1! OWNERS MANUAL(EN) A7340EP 1EMN22243
X2-2! OWNERS MANUAL(FR) A7340EP 1EMN22244
X2-3! OWNERS MANUAL(DE) A7340EP 1EMN22245
X2-4! OWNERS MANUAL(IT) A7340EP 1EMN22246
X2-5! OWNERS MANUAL(ES) A7340EP 1EMN22247
X2-6! OWNERS MANUAL(NL) A7340EP 1EMN22248
X2-7! OWNERS MANUAL(SV) A7340EP 1EMN22249
X2-8! OWNERS MANUAL(RU) A7340EP 1EMN22250
X2-9! OWNERS MANUAL(PL) A7340EP 1EMN22251
X2-10! OWNERS MANUAL(HU) A7340EP 1EMN22252
X2-11! OWNERS MANUAL(CS) A7340EP 1EMN22253
X2-12! OWNERS MANUAL(EL) A7340EP 1EMN22254
X2-13! OWNERS MANUAL(SK) A7340EP 1EMN22255
X2-14! OWNERS MANUAL(AR) A7340EP 1EMN22256
X2-15! OWNERS MANUAL(PT) A7340EP 1EMN22257
X2-16! OWNERS MANUAL(RO) A7340EP 1EMN22258
X2-17! OWNERS MANUAL(BG) A7340EP 1EMN22259
X3 REMOTE CONTROL NF019RD 170/
ECNLC501/NF019RD
NF019RD
X4 BATTERY R6RC/2P XB0M601MS001
Ref. No. Description Part No.
