ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
LCD MAIN CBA UNIT & LIQUID
CRYSTAL PANEL UNIT
MMA CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
LCD MAIN CBA UNIT & LIQUID CRYSTAL
PANEL UNIT
UF200EA
Ref. No. Description Part No.
MMA CBA
Consists of the following:
1ESA14614
MAIN CBA
FUNCTION CBA
IR SENSOR CBA
JUNCTION-A CBA
JUNCTION-B CBA
----------
----------
----------
----------
----------
Ref. No. Description Part No.
MAIN CBA
Consists of the following:
----------
CAPACITORS
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C15 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M or CA1A101SP085
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTM101
C16 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C18 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C20 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C21 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M or CA1C470SP085
ALUMINUM ELECTROLYTIC CAP 47µF/16V M CE1CMASTM470
C22 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C24 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C25 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C35 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C402 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C403 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
C405 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M or CA1J1R0SP085
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C421 CAP CHIP 5pF 3KV C XC or CA3F5R05M016
CAP CHIP CERAMIC 5pF/3.15KV/DJ CA3F5R0MR060
C422 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C423 CAP CHIP 5pF 3KV C XC or CA3F5R05M016
CAP CHIP CERAMIC 5pF/3.15KV/DJ CA3F5R0MR060
C425 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C426 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C427 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C428 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C429 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C430 CAP METALIZED FILM 0.068/250VDC/J/MPEF
or
CT2E683DT051
CAP POLYPROPYLENE 0.068µF/250V J or CA2E683DT038
CAP POLYPROPYLENE 0.068µF/250V J CA2E683DT039
C431 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
C432 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C461 CAP CHIP 5pF 3KV C XC or CA3F5R05M016
CAP CHIP CERAMIC 5pF/3.15KV/DJ CA3F5R0MR060
C462 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C463 CAP CHIP 5pF 3KV C XC or CA3F5R05M016
CAP CHIP CERAMIC 5pF/3.15KV/DJ CA3F5R0MR060
C465 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C466 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C467 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C468 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C469 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C470 CAP METALIZED FILM 0.068/250VDC/J/MPEF
or
CT2E683DT051
CAP POLYPROPYLENE 0.068µF/250V J or CA2E683DT038
CAP POLYPROPYLENE 0.068µF/250V J CA2E683DT039
C471 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
C472 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C600! METALIZED FILM CAP. 0.22µF/250V or CT2E224MS037
! ACROSS THE LINE CAP. 0.22µF/250V or CT2E224DC017
! CAP METALIZED FILM 0.22µF/300V K 3.5MM CT2F224DC004
C616! CAP ELECTROLYTIC 180µF/400V M CA2H181DYG10
C621 CERAMIC CAP. 470pF/2KV or CA3D471PAN04
CERAMIC CAP. RB 470pF/2KV or CA3D471TE006
CERAMIC CAP. BL 470pF/2KV CA3D471XF003
C622 FILM CAP.(P) 0.001µF/50V J or CMA1JJS00102
FILM CAP.(P) 0.001µF/50V J or CA1J102MS029
POLYESTER FILM CAP. (PB FREE) 0.001µF/
100V J or
CA2A102DT018
CAP POLYESTER FILM 0.001µF/50V J CA1J102SER04
C623 FILM CAP.(P) 0.01µF/50V J or CMA1JJS00103
FILM CAP.(P) 0.01µF/50V J or CA1J103MS029
POLYESTER FILM CAP. (PB FREE) 0.01µF/
100V J or
CA2A103DT018
