20070911 13-3 A7340EL
ELECTROLYTIC CAP. 0.47µF/50V M or CA1JR47SP085
ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASTMR47
C902 ELECTROLYTIC CAP. 2200µF/25V M or CE1EMZPDL222
ALUMINUM ELECTROLYTIC CAP 2200µF/25V
M or
CE1EMZNTM222
ELECTROLYTIC CAP. 2200µF/25V M CE1EMZNDL222
C903! ELECTROLYTIC CAP. 100µF/50V M or CE1JMASDL101
! ELECTROLYTIC CAP 100µF/50V M or CA1J101SP085
! ELECTROLYTIC CAP 100µF/50V M CE1JMASTM101
C904! ELECTROLYTIC CAP. 470µF/25V M or CE1EMASDL471
! ELECTROLYTIC CAP. 470µF/25V M or CA1E471SP085
! ALUMINUM ELECTROLYTIC CAP 470µF/25V
M
CE1EMASTM471
C905! ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
! ELECTROLYTIC CAP. 100µF/16V M or CA1C101SP085
! ELECTROLYTIC CAP. 100µF/16V M CE1CMASTM101
C906! ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
! ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085
! ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221
C908 CERAMIC CAP. 1000pF/2KV or CA3D102PAN04
CERAMIC CAP RB 1000pF/2KV or CA3D102TE006
CERAMIC CAP. BL 1000pF/2KV CA3D102XF003
C909 FILM CAP.(P) 0.0027µF/50V J or CMA1JJS00272
FILM CAP.(P) 0.0027µF/50V J or CA1J272MS029
POLYESTER FILM CAP. (PB FREE) 0.0027µF/
100V J or
CA2A272DT018
CAP POLYESTER FILM 0.0027µF 50V J CA1J272SER04
C910 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/50V M or CA1J220SP085
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
C911! ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
! ELECTROLYTIC CAP. 470µF/16V M or CA1C471SP085
! ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C912 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/50V H7 CE1JMAVSM1R0
C914 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C916 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C919 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C921 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C922 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C924 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/16V H7 CE1CMAVSM100
C926 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C929 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M or CA1A101SP085
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTM101
C930 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C941 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M or CA1J100SP085
ALUMINUM ELECTROLYTIC CAP 10µF/50V M CE1JMASTM100
C950 ELECTROLYTIC CAP. 220µF/6.3V M or CE0KMASDL221
ELECTROLYTIC CAP. 220µF/6.3V M or CA0K221SP085
ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASTM221
C951 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M or CA1C221SP085
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTM221
C952 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/16V H7 CE1CMAVSM100
C953 ELECTROLYTIC CAP. 330µF/6.3V M or CE0KMASDL331
ELECTROLYTIC CAP. 330µF/6.3V M or CA0K331SP085
ALUMINUM ELECTROLYTIC CAP 330µF/6.3V
M
CE0KMASTM331
CONNECTORS
CN01 TERMINAL PRINTBORD PIN MS-PIN155155 JTEA001CHY01
CN02 TERMINAL PRINTBORD PIN MS-PIN155155 JTEA001CHY01
CN53 CONNECTOR PRINT OSU B5B-PH-K-S
(LF)(SN) or
J3PHC05JG029
Ref. No. Description Part No.
CONNECTOR PRINT OSU C S 440054-5 J344C05AP001
CN101A TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN102A TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN103A TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN401 BACK LIGHT CONNECTOR 1717369-1 JB17D02AP001
CN403 BACK LIGHT CONNECTOR 1717369-1 JB17D02AP001
CN901 PH CONNECTOR TOP 4P B4B-PH-K-S
(LF)(SN) or
J3PHC04JG029
CONNECTOR PRINT OSU C S 440054-4 J344C04AP001
DIODES
D13 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D55 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D56 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D401 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D402 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D403 ZENER DIODE MTZJT-777.5B QDTB0MTZJ7R5
D404 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D406 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D407 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D408 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
DIODE ZENER HZS6C2 TD-E QDTC000HZS62
D409 ZENER DIODE MTZJT-7710B or QDTB00MTZJ10
DIODE ZENER HZS11A1 TD-E QDTA00HZS111
D410 ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D411 ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D421 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D422 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D423 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D424 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D425 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D426 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D427 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D428 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D429 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D430 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D431 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D432 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D433 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D434 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D461 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D462 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D463 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
Ref. No. Description Part No.
