FUNAI LC5-D20BB - Page 51

20070911 13-10 A7340EL
FUNCTION CBA
IR SENSOR CBA
JUNCTION-A CBA
JUNCTION-B CBA
F601! FUSE 4A/250V(PB FREE) 0215004.MXP PBGZ20BAG021
FH601 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH602 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
J128 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
JK721 Y/C JACK YKF51-5646N or JYEJ040JC001
JACK SW DIN PCB S 04/DIN-417HA-01 JYEJ040YUQ03
JK722 RCA JACK AV-4B-54H YELLOW or JXRJ010SNJ01
JACK RCA PCB S YELLOW 01/RCA-101H(YL) JXRJ010YUQ05
JK723 RCA JACK WHITE AV-4B-58H WHITE or JXRJ010SNJ04
JACK RCA PCB S WHITE 01/RCA-101H(WH) JXRJ010YUQ02
JK724 RCA JACK AV-4A-57H RED or JYRJ010SNJ01
JACK SW RCA PCB S RED RCA-102H(RD) JYRJ010YUQ03
JK751 JACK RGB PCB S 21PIN / MRC-021H-02 JXGJ210LY001
JK801 MINIATURE JACK(PB FREE) CKX-035-318AZ4
or
JYSL010SNJ01
JACK SW HPEP SML PCB L PJ-350 JYSL010YUQ03
JS426 PCB JUMPER D0.6-P5.0 JW5.0T
JS466 PCB JUMPER D0.6-P18.5 JW18.5T
JS605 PCB JUMPER D0.6-P10.0 JW10.0T
JS606 PCB JUMPER D0.6-P10.0 JW10.0T
JS607 PCB JUMPER D0.6-P10.0 JW10.0T
JS608 PCB JUMPER D0.6-P10.0 JW10.0T
JS810 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
JS863 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
JS864 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
L16 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA600 SURGE ABSORBER 470V+-10PER or NVQZ10D471KB
VARISTOR 10D 471K SVR NVQZVR10D471
T401! TRANS INVERTER ETJV27ZK27AC or LTZ2PC0MS006
! TRANS INVERTER 1167TG-1014 LTZ2PC0TK001
T403! TRANS INVERTER ETJV27ZK27AC or LTZ2PC0MS006
! TRANS INVERTER 1167TG-1014 LTZ2PC0TK001
T601! TRANS POWER 7721 LTT2PE0KT025
TM601 EYELET TYPE D-1 0VM406868
TM602 EYELET TYPE D-1 0VM406868
X860 XTAL OSCILLATOR 27.00MHz 15PPM FXC276LLN002
Ref. No. Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITOR
C33 CERAMIC CAP.(AX) F Z 0.01µF/25V CCA1EZTFZ103
CONNECTOR
CN51A WIRE ASSEMBLY 4PIN SW 4PIN 140MM WX1A7340-003
RESISTORS
R24 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R25 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R26 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R27 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002
R28 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R29 CHIP RES. 1/10W J 2.7k Ω or RRXAJR5Z0272
RES CHIP 1608 1/10W J 2.7k Ω RRXA272YF002
R30 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R31 CHIP RES. 1/10W J 6.8k Ω or RRXAJR5Z0682
RES CHIP 1608 1/10W J 6.8k Ω RRXA682YF002
R32 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R33 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
SWITCHES
SW30 TACT SWITCH SKHHARA010 or SST0101AL060
Ref. No. Description Part No.
TACT SWITCH KSMC622A SST0101HH031
SW31 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW32 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW33 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW34 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW36 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
SW37 TACT SWITCH SKHHARA010 or SST0101AL060
TACT SWITCH KSMC622A SST0101HH031
Ref. No. Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITORS
C12 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C61 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
DIODES
D51 LED L-53HT or NP4Z000L53HT
LED LAMP 333HT/F45-50L NPWL333HTF45
RESISTORS
R64 CARBON RES. 1/4W J 120 Ω RCX4JATZ0121
R65 CARBON RES. 1/4W J 120 Ω RCX4JATZ0121
R66 CARBON RES. 1/4W J 120 Ω RCX4JATZ0121
MISCELLANEOUS
CLN53 WIRE ASSEMBLY 5PIN SENSOR 5PIN 130MM WX1A7340-004
JS51 PCB JUMPER D0.6-P7.0 JW7.0T
JS52 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
JS53 PCB JUMPER D0.6-P5.0 JW5.0T
RCV51 REMOCON RECEIVE UNIT KSM-602SR2E-2 or USESJRSKK045
REMOCON RESEVER MIM-0BM8DKL-C USESJRSUNT07
Ref. No. Description Part No.
JUNCTION-A CBA
Consists of the following:
----------
CAPACITOR
C891 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
CONNECTOR
CN801 WIRE ASSEMBLY 2PIN SPEAKER(R) 2PIN
220MM
WX1A7340-002
Ref. No. Description Part No.
JUNCTION-B CBA
Consists of the following:
----------
CAPACITOR
C892 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
CONNECTOR
CN802 WIRE ASSEMBLY 2PIN SPEAKER(L) 2PIN
180MM
WX1A7340-001
Ref. No. Description Part No.
MISCELLANEOUS
AC601! AC CORD CEE 1800MM BLACK WAE0182LW003
TU1 TUNER UNIT BS TMFE6-301A UTUNPLGAL018
Ref. No. Description Part No.
