TAIPAN PEDALS 2024.04.15 / REV. 0
WWW.FUNNMTB.COM
BEARING / Axle Replacement
step 13 :
step 14 :
Reattach the side cap using a 6mm hex key. After installation, check that the axle rotates
smoothly and is free from any side-to-side movement.
Insert the spacer around the axle nut in the pedal body.
6mm hex key
5-6Nm
FUUNDAMENTAL PEDALS
FUNNDAMENTAL PEDALS 2024.04.23 / REV. 0
08
