BEARING / Axle Replacement
new axle kit
tools required
Welcome to the Funndamental Pedals Bearing and Axle Replacement Guide
Before beginning the maintenance on Funndamental pedals, ensure a seamless process by utilizing high-quality tools to avoid
damaging the screw sockets. It's advisable to service your pedals one side at a time to avoid mixing up parts. Additionally, be
mindful of thread directions, as indicated by diagrams on both sides of the pedal, and pay special attention when handling
these specific parts.
8mm socket wrench
8mm hex key
6mm hex key
3mm hex key
Plastic hammer
Bushing press
Bushing remover
7mm open-end wrench
Tweezers
Bearings
M4 bolt M4 nut
Axle nutsSpacersOuter seals O-rings Side capsSpacersBushingsPedal axles
Spacer
