4
About your Product
English
General Information
Through the use of MPPT technology,
the Furrion MPPT series can increase
charge current by up to 30% compared to
conventional PWM controllers. Furrion’s
sophisticated three stage charge control
system can be configured to optimize charge
parameters to precise battery requirements.
The unit is fully protected against voltage
transients, over temperature, reverse
battery and reverse PV connections. Fully
automatic temperature compensation of
charge voltage is available to further improve
charge control and battery performance. The
sensor element is environmentally sealed
and encapsulated into a connection lug which
directly connects to the battery terminals.
Furrion MPPT charge controller with RV-C
communication bus interface and RV-C CAN
bus communication protocol is available to
meet the communication requirements in RV.
Key Features
Ɣ Compatible with 12V or 24V battery
system.
Ɣ Advanced maximum power point tracking
technology to optimize the use of the PV
system. High tracking efficiency of 99%.
Ɣ High open circuit voltage of PV input.
Ɣ Battery is active in low voltage state.
Ɣ Sealed, AGM and LiFePO4 Lithium battery
option.
Ɣ ECO mode, automatic recognition of day
and night.
Ɣ Temperature compensation and
corrective charging.
Ɣ RV-C CAN bus communication protocol.
Ɣ Reverse protection: Any combination
of solar modules and batteries can be
made without causing damage to any
component.
Ɣ Electronic protection: overcharging, over
temperature, over PV input power.
Ɣ Easy to assemble: simply slide the
controller into the Furrion Solar Charger
Mounting Bracket (model FSCC60PWM
not included).
