Furrion NET-ZERO FSCC30PW-BL User Manual

6
Maximum Power Point Tracking (MPPT)
English
The Furrion solar MPPT Controller can charge up to 30% more compared to traditional PWM
charge controllers.
Upper curve:
Output current (I) of a solar panel as function of output voltage (V). The maximum power point
(MPP) is the point Pmax along the curve were the product I x V reaches its peak.
V
Imp
Short
circuit
current
I
Pmax
Lower curve:
Output power P = I x V as function of output voltage. When using a PWM (not MPPT) controller
the output voltage of the solar panel will be nearly equal to the voltage of the battery, and will
be lower than Vmp.
V
Vmp
Vdc
P
Pmax
