Outside dimensions
2 – 4
n
nn
n B-box n
nn
n T-box
Model
Item
F1 F2 F3 F4 F5
Side bracket mm 899 1015 1115 1230 1352
Total Bracket mm 1009 1095 1255 1335 1458
length B-BOX mm 1241 1395 1507 1689
Dimen- T-BOX mm 1050 1159 1255 1369
sion B Outside of bracket mm 180 180 214 235 235
C Inside of bracket mm 130 130 154 175 175
D Inner diameter of boss mm ∅45 ∅45 ∅60 ∅60 ∅60
E Rod diameter mm ∅36 ∅45 ∅52 ∅ 60 ∅68
F Effective length mm 260 290 325 350 372
124 187 187 233 233
Side bracket mm
161 215 246 277 277
Bracket mm 140 195 215 280 280
G
Distance
Between
Pins
B-BOX mm 150 240 251 282
A
A
F
D
B
C
E
A
F
E
