Outside dimensions
2 – 7
Oil hose plug and cap
NOTICE
When attaching/detaching the oil hose plug and union cap, clean them well to prevent
entry of dust.
Oil hose plug The oil hose plug is used to plug the hose attached to the
hydraulic breaker. It prevents mud or dust from entering the hose when the hydraulic breaker is
removed from the base machine for bucket operation, etc.
Model Part No. Parts Name Q’ty
F1 084899-03000 9 Oil hose plug 2
F2
F3
F4
F5
The union cap is used to cap the piping bracket attached to the base machine for prevention of the
piping bracket from being smeared with mud during bucket
operation, etc.
Model Part No. Parts Name Q’ty
F1 084899-03000 9 Union cap 2
F2
F3
F4
F5
NOTICE
Keep the removed union cap and hose plug in the tool box.
Union cap
084899-04000 12 Oil hose plug 2
084899-04000 12 Union cap 2
