Outside dimensions
2 – 6
Type of rod and major applications
Type of rods Shape Major applications
Flat rod
Concrete breaking
Moil point
Multipurpose applications, including breaking of
reinforced concrete, as well as excavation of
bedrock
Wedge point
Concrete breaking, excavation of bedrock,
operations on the face of slope, excavation of
ditches, etc.
Core rod
(Ball-point rod)
Breaking metal ores, as well as quartzite and
other highly abrasive objects
• Furukawa rods come in a moil point, wedge point, flat rod, and rod with cemented carbide core. In
general, the moil point is used frequently, but select an appropriate rod according to the nature of
work and the characteristics of the object to break.
n
nn
n Dimension/weight of rod
Model
Item
F1 F2 F3 F4 F5
Rod dia. (mm) 36 45 52 60 68
Total length (mm) 400 460 510 560 600
Effective length (mm) 260 290 325 350 372
Use limit (mm) 185 215 225 240 252
Mass (kg) 2.8 5.0 8.0 11.0 15.0
Use limit
Effective length
Total length
