Mounting
When selecting a location, keep in mind the following points. Fix the power supply unit on the
desktop or bulkhead with four self-tapping screws (4x20, supplied).
• Location is dry, well ventilated.
• Make sufficient maintenance space.
• Installed within 2, 5 or 10 m (2 and 10 m: optional supply) from the multi function display.
Note: When you install the unit on the bulkhead, fix the unit with the following direction.
Self-tapping screw
(4x20, 4 pcs.)
UP
