[SPEED]
Table 3.2.4 SPEED Box Menu
Menu Submenu Description
1 SHIP SPEED
LOG(BT)/LOG(WT)/GPS/
MANUAL/REF
Allows the selection of ship speed data.
The sentences are;
LOG (WT): VBW>VHW, LOG (BT): VBW
GPS: VTG>RMC
Note:
The speed of the own ship is calculated with
reference to static targets like a buoy. Up to three
static targets (R1-R3) can be specified, and
averaged value is displayed as XX BT/REF in the
[SPD] box menu. The target is acquired in one
minute after it is specified. The target is displayed
as “R1,” for instance.
In the IMO radar, the manual speed and reference
speed are not available.
2 MANUAL SPEED 0.0 kt
When “MANUAL” is selected in “1 SHIP SPEED”
listed above, the ship speed is entered.
3 SET DRIFT OFF/ON
“SET DRIFT” should be entered in setting other
than BT. In the IMO radar, when [Menu] -> 4 -> 8:
AIS FUNCTION is set to ON, “SET DRIFT” is kept
OFF. Expect for the IMO type radar, when this
menu box is turned off, it changes to the 2nd cursor
data box.
[TGT LIST]
Table 3.2.5 TGT LIST Box Menu
Menu Submenu Description
1 SORT BY
CPA/TCPA/BCR/BCT/
RANGE/SPEED
(CPA/TCPA/BCR/BCT/
RANGE/SPEED)
Sets the order for sorting ARPA and AIS targets in
the target list.
[SPEED MENU]
1 SHIP SPEED
LOG(BT)/LOG(WT)/
GPS/MANUAL*/REF*
2 MANUAL SPEED
0.0kt
3 SET DRIFT
OFF/ON*
* Not available on IMO radar.
