Furuno FAR-3310 User Manual

12. ROUTES
12-18
12.8.3 How to import csv, ASCII format route data
1. Set the USB flash memory to the USB
port on the Control Unit.
2. Activate the Voyage planning mode.
3. On the InstantAccess bar, click the
[Manage Data], [Route] and [Route
Data Management] buttons to show
the [Route Data Management] dialog
box.
4. At the drop-down list, select the im-
port format. The choices are [FEA-
2x07], [CSV Position], [ASCII WPT
Name Position], [ASCII Full], [CSV
Route Sheet], [RTE Format].
5. Click the [Import] button.
6. Select the file to import then click the
[Open] button.
7. Click the [Close] button to close the dialog box.
12.9 How to Export Route Data
12.9.1 How to export FAR-3xx0 route data
You can export route data to share the data with other FCR-2xx9, FMD-3xx0, FAR-
3xx0 units.
1. Set a USB flash memory in the USB port on the Control Unit.
2. Click the [ ] button on the Status bar and select [Settings]. The confirmation
message appears.
3. Click the [OK] button.
4. Click the [File Export] tab.
5. At [Select data to export], check only [Route/User chart].
6. Click the [Export] button to save the data to the USB flash memory.
Radar Installation

Furuno FAR-3310 Specifications

General

Type	Marine Radar
Display Type	LCD
Antenna Type	Open Array
Input Voltage	24 VDC
Frequency	9410 MHz ± 30 MHz
Range	Up to 96 nautical miles
Range Scales	0.125, 0.25, 0.5, 1, 2, 4, 8, 12, 16, 24, 32, 48, 64, 96 nm
Antenna Length	4 feet
Beamwidth	1.9° (Horizontal)
Rotation Speed	24 RPM
