Furuno FELCOM 12 Installation Manual

7
XXXXXXXXXXXXXXXXXX XXXXXXXXXXXX
XXXX XXXX XXXX
XXXX
Copper strap (1.2 m) for
grounding
16S0042, 3 m
* Fit connectors or crimp-on lugs in field.
Ship’s Mains
24 VDC
Navigation
Device
IB-581
or
Personal
Computer
IB-581
or
EGC Printer
16S0068, 5 m
VCTF 0.75x2C, 3 m
24 VDC
16S0084, 5 m
3 m
2 m
Terminal
Unit
IB-581
Printer PP-510
Ground
wire
Ground wire
Antenna Unit
IC-112
Communication Unit
IC-212
Distress
Alert
Unit
IC-302
Distress
Alert
Unit
IC-302
Received
Call
Unit
IC-303
5D-FB-CV, 30 m
8D-FB-CV, 50 m
12D-SFA-CV, 100 m
*
*
0.37 m
TTYCS-3
(local supply)
(NMEA0183;GLL/VTG/WPL/
RMA/RMB/RMC/GGA)
***
4.WIRING
Figure 4-1General wiring diagram
