4-1
4. HOW TO INSTALL OPTIONAL
EQUIPMENT
The optional waterproofing kits OP16-58 and OP16-61 are used to protect the con-
nectors on the communication unit from water splash. Note that these optional kits
should be used as a couple.
4.1 IPX2 Kit OP16-58 (cables)/Waterproofing Kit
OP16-60 (for IC-318)
OP16-58
Connect the waterproofed D-sub cables to the rear of the communication unit, instead
of the standard supply cable.
OP16-58 (Code No.: 001-180-070)
OP16-60
To mount the IC-318 on a bulkhead, use the waterproofing kit to keep water splash
out of the unit. When the OP16-58 is used, replace the cable from the IC-318 with the
XM-FD-361 as shown on next page.
OP16-60 (Code No.: 001-180-090)
Name Type Code No. Qty Remarks
Cable Assy. H230817-1 001-176-552-10 1 Not used.
H230817-2 000-176-553-10 1 Not used.
XM-FD-361 000-176-551-10 1 For connection with IC-318
Name Type Code No. Qty
Cover gasket 16-023-5502 100-373-530-10 1
Grommet 16-023-5503 100-373-540-10 1
To Next Page
