SYSTEM CONFIGURATION
Antenna Unit Exposed to Weather
Communication Unit Protected from Weather
Other Units Protected from Weather
PERSONAL
COMPUTER
(PC/AT compatible)
ANTENNA
UNIT
IC-119
COMMUNICATION
UNIT IC-219 (with
internal GPS receiver)
POWER SUPPLY
100-115/200-230
1φ, 50/60 Hz
POWER SUPPLY
12-24 VDC
AC/DC
Power Supply
PR-240
PRINTER
JUNCTION BOX
IC-318
SSAS ALERT UNIT*
IC-307
SSAS ALERT UNIT*
IC-307
*: At least two SSAS Alert Units are required.
CATEGORY OF UNITS
(Max. 3 units)
Navigation Equipment
(GNSS)
POWER SUPPLY
24 VDC
