Furuno felcom15 - FELCOM 12 SSAS System Diagram

3
FELCOM 12
Navigator
: Standard
: Option
: User Supply
INMARSAT-C MOBILE EARTH STATION
POWER
ON OFF
POWER BRIGHT CONTRAST
Antenna Unit
IC-112
Terminal Unit
IB-581/IB-582
24 VDC
Communication
Unit
IC-212
Mini Keyboard
24 VDC
Priinter
PP-510
24 VDC
100/110/200/220V
1φ, 50/60 Hz
AC-DC
Power Supply
PR-300
Distress Alert Unit
IC-302
Received Call Unit
IC-303
Distress Alert Unit
IC-302
OR
Distress Message Controller
DMC-5
24 VDC
PC
(PC/AT compatible)
OR
Terminal Unit
IB-581/IB-582
SSAS Alert Unit
IC-307
SSAS Alert Unit
Interface
IC-312
24 VDC
SSAS Alert Unit
IC-307
(Max. 3 units)
SSAS Alert Unit
IC-307
