3-4
Figure 3.5 Display Unit, top view, drawing forward
Figure 3.6 Display pedestal, for side, shield cover removed
PTU Board
(AC : 03P9245, DC : 03P9246)
Shield cover removed
Power Switch for
Maintenance
Fuse (F1)
Fuse
(
F2
)
